1.1 Features
MCU
• ESP32-D0WD-V3 embedded, Xtensa
®
dual-core
32-bit LX6 microprocessor, up to 240 MHz
• 448 KB ROM for booting and core functions
• 520 KB SRAM for data and instructions
• 16 KB SRAM in RTC
WiFi
• 802.11b/g/n
• Bit rate: 802.11n up to 150 Mbps
• A-MPDU and A-MSDU aggregation
• 0.4 µs guard interval support
• Center frequency range of operating channel:
2412 ~ 2484 MHz
Bluetooth
®
• Bluetooth V4.2 BR/EDR and Bluetooth LE
specification
• Class-1, class-2 and class-3 transmitter
• AFH
• CVSD and SBC
Hardware
• Interfaces: SD card, UART, SPI, SDIO, I
2
C, LED
PWM, Motor PWM, I
2
S, IR, pulse counter, GPIO,
capacitive touch sensor, ADC, DAC, Two-Wire
Automotive Interface (TWAI
®
, compatible with
ISO11898-1)
• 40 MHz crystal oscillator
• 4 MB SPI flash
• Operating voltage/Power supply: 3.0 ~ 3.6 V
• Operating temperature range: –40 ~ 85 °C
• Dimensions: See Table 1
Certification
• Bluetooth certification: BQB
• RF certification: FCC/CE-RED/SRRC
• Green certification: REACH/RoHS
1.2 Description
ESP32-WROOM-32E and ESP32-WROOM-32UE are two powerful, generic Wi-Fi+BT+BLE MCU modules that
target a wide variety of applications, ranging from low-power sensor networks to the most demanding tasks,
such as voice encoding, music streaming and MP3 decoding.
ESP32-WROOM-32E comes with a PCB antenna, and ESP32-WROOM-32UE with an IPEX antenna. They both
feature a 4 MB external SPI flash. The information in this datasheet is applicable to both modules.
The ordering information of the two modules is listed as follows:
Table 1: Ordering Information
Module Chip embedded Flash Module dimensions (mm)
ESP32-WROOM-32E (PCB)
ESP32-D0WD-V3 4 MB
1
18.0 × 25.5 × 3.1
ESP32-WROOM-32UE (IPEX) 18.0 × 19.2 × 3.2
Notes:
1. The module with 8 MB flash or 16 MB flash is available for custom order.
2. For detailed ordering information, please see Espressif Product Ordering Information.
3. For dimensions of the IPEX connector, please see Chapter 7.3.
