BSC112N06LD
Rev.2.0,2018-12-11Final Data Sheet
1
2
3
4
5
6
7
8
4
1
2
3
5
6
7
8
PG-TDSON-8-4
S1
G1 S2
G2
D1 D1 D2 D2
MOSFET
OptiMOS
TM
-T2PowerTransistor,60V
Features
·DualN-channel,Logiclevel
·FastswitchingMOSFETsforSMPS
·OptimizedtechnologyforSynchronousRectification
·Pb-freeplating;RoHScompliant
·100%Avalanchetested
·SuperiorThermalResistance
·Halogen-freeaccordingtoIEC61249-2-21
ProductValidation
Qualifiedforindustrialapplicationsaccordingtotherelevanttestsof
JEDEC47/20/22
Table1KeyPerformanceParameters
Parameter Value Unit
V
DS
60 V
R
DS(on),max
11.2 mΩ
I
D
20 A
Type/OrderingCode Package Marking RelatedLinks
BSC112N06LD SSO8 dual (TDSON-8-4) 112N06LD -
