采用小型封装、具有 ±15kV IEC ESD 保护的

TRS3221E 3V 至 5.5V 单通道 RS-232 线路驱动器/接收器

1 特性

• 为 RS-232 引脚提供 ESD 保护

– ±15kV 人体放电模型 (HBM)

– ±8kV（IEC 61000-4-2，接触放电）

– ±15kV（IEC 61000-4-2，空气间隙放电）

• 符合或超出 TIA/EIA-232-F 和 ITU v.28 标准的要求

• 由 3V 至 5.5V V

电源供电

• 外部电容器：4 × 0.1μF

• 接受 5V 逻辑输入及 3.3V 电源

• 备选高速引脚兼容器件（1Mbit/s）

– TRSF3221E

• 自动断电功能可自动禁用驱动器以节省能耗

2 应用

• 电池供电手持式和便携式设备

• PDA 和掌上电脑

• 笔记本电脑、小型笔记本电脑

• 数码相机

要求并在异步通信控制器与串行端口连接器之间提供电

气接口。电荷泵和四个小型外部电容器支持由 3V 至

5.5V 单电源供电。这些器件以高达 250kbit/s 的数据信

号传输速率和最高为 30V/μs 的驱动器输出压摆率运

行。

串行端口处于非活动状态时，可提供灵活的电源管理控

制选项。当 FORCEON 为低电平且 FORCEOFF 为高

电平时，自动断电功能启用。在这种运行模式下，如果

器件在接收器输入中未感应到有效的 RS-232 信号，则

禁用驱动器输出。如果

器输入中是否存在 RS-232 信号。如果接收器输入电压

大于 2.7V 或小于 -2.7V，或者介于 -0.3V 至 0.3V 之间

有关接收器输入电平的信息，请参阅图 7-5。

(1) 如需了解所有可用封装，请参阅数据表末尾的可订购产品附

录。

本文档旨在为方便起见，提供有关 TI 产品中文版本的信息，以确认产品的概要。有关适用的官方英文版本的最新信息，请访问

www.ti.com，其内容始终优先。TI 不保证翻译的准确性和有效性。在实际设计之前，请务必参考最新版本的英文版本。

English Data Sheet: SLLS792

6 Specifications.................................................................. 4

6.1 Absolute Maximum Ratings........................................ 4

6.2 ESD Ratings............................................................... 4

6.3 ESD Ratings, IEC Specifications................................ 4

6.4 Recommended Operating Conditions.........................5

6.5 Thermal Information....................................................5

6.6 Electrical Characteristics.............................................5

6.7 Driver Section Electrical Characteristics..................... 6

6.8 Driver Section Switching Characteristics.................... 6

6.9 Receiver Section Electrical Characteristics................ 7

7 Parameter Measurement Information.......................... 10

8 Detailed Description......................................................13

8.1 Overview................................................................... 13

8.2 Functional Block Diagram......................................... 13

8.3 Feature Description...................................................13

8.4 Device Functional Modes..........................................14

9 Application Information Disclaimer............................. 15

9.1 Application Information............................................. 15

9.2 Typical Application.................................................... 15

9.3 Design Requirements............................................... 16

Information.................................................................... 18

注：以前版本的页码可能与当前版本的页码不同

Changes from Revision * (June 2007) to Revision A (December 2020) Page

• 添加了 ESD

、IEC

表、

部分、

部分、

部分以及

部分..........................................1

• 删除了

表.............................................................................................................................................. 1

• Added the RGT (VQFN-16) package pinout ......................................................................................................3

• Added data rate and t

rows for the RGT package in Driver Section Switching Characteristics table ..........6

Submit Document Feedback

Copyright © 2021 Texas Instruments Incorporated

Product Folder Links: TRS3221E

Product Folder Links: TRS3221E
