uA9637AC
DUAL DIFFERENTIAL LINE RECEIVER
SLLS111B – SEPTEMBER 1980 – REVISED MAY 1995
1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
D
Meets or Exceeds the Requirements of
ANSI Standards EIA/TIA-422-B and
EIA/TIA-423-B and ITU Recommendations
V.10 and V.11
D
Operates From Single 5-V Power Supply
D
Wide Common-Mode Voltage Range
D
High Input Impedance
D
TTL-Compatible Outputs
D
High-Speed Schottky Circuitry
D
8-Pin Dual-in-Line and Small-Outline
Packages
D
Designed to Be Interchangeable With
National DS9637A
description
The uA9637AC is a dual differential line receiver designed to meet ANSI Standards EIA/TIA-422-B and
EIA/TIA-423-B and ITU Recommendations V.10 and V.11. The line receiver utilizes Schottky circuitry and has
TTL-compatible outputs. The inputs are compatible with either a single-ended or a differential-line system. This
device operates from a single 5-V power supply and is supplied in an 8-pin dual-in-line package or small-outline
package.
The uA9637AC is characterized for operation from 0°C to 70°C.
logic symbol
†
†
This symbol is in accordance with ANSI/IEEE Std 91-1984 and
IEC Publication 617-12.
2OUT
1OUT
5
6
7
8
2IN–
2IN+
1IN–
1IN+
3
2
logic diagram
2IN–
2IN+
1IN–
1IN+
5
6
7
8
3
2
2OUT
1OUT
Copyright 1995, Texas Instruments Incorporated
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
1
2
3
4
8
7
6
5
V
CC
1OUT
2OUT
GND
1IN+
1IN–
2IN+
2IN–
uA9637AC ...D OR P PACKAGE
(TOP VIEW)

uA9637AC
DUAL DIFFERENTIAL LINE RECEIVER
SLLS111B – SEPTEMBER 1980 – REVISED MAY 1995
2
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
schematics of inputs and outputs
EQUIVALENT OF EACH INPUT
TYPICAL OF ALL OUTPUTS
Current
Source
Input
8 kΩ
V
CC
Output
V
CC
50 Ω NOM
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
†
Supply voltage range, V
CC
(see Note 1) –0.5 V to 7 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage, V
I
±15 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Differential input voltage, V
ID
(see Note 2) ±15 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output voltage range, V
O
(see Note 1) –0.5 V to 5.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low-level output current, I
OL
50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous total dissipation See Dissipation Rating Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating free-air temperature range, T
A
0°C to 70°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range, T
stg
–65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds 260°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
†
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES: 1. All voltage values, except differential input voltage, are with respect to the network ground terminal.
2. Differential input voltage is measured at the noninverting input with respect to the corresponding inverting input.
DISSIPATION RATING TABLE
PACKAGE
T
A
≤ 25°C
POWER RATING
OPERATING FACTOR
ABOVE T
A
= 25°C
T
A
= 70°C
POWER RATING
T
A
= 125°C
POWER RATING
D 725 mW 5.8 mW/°C 464 mW —
P 1000 mW 8.0 mW/°C 640 mW —

uA9637AC
DUAL DIFFERENTIAL LINE RECEIVER
SLLS111B – SEPTEMBER 1980 – REVISED MAY 1995
3
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
recommended operating conditions
MIN NOM MAX UNIT
Supply voltage, V
CC
4.75 5 5.25 V
Common-mode input voltage, V
IC
±7 V
Operating free-air temperature, T
A
0 70 °C
electrical characteristics over recommended ranges of supply voltage, common-mode input
voltage, and operating free-air temperature (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP
†
MAX UNIT
V
IT
Positive going in
p
ut threshold voltage
See Note 3
0.2
V
V
IT+
Positi
v
e
-
going
inp
u
t
threshold
v
oltage
See
Note
3
0.4
V
V
Negative going input threshold voltage
See Note 3
–0.2
V
V
IT–
N
ega
ti
ve-go
i
ng
i
npu
t
th
res
h
o
ld
vo
lt
age
S
ee
N
o
t
e
3
–0.4
‡
V
V
hys
Hysteresis voltage (V
IT+
–V
IT–
) 70 mV
V
OH
High-level output voltage V
ID
= 0.2 V, I
O
= –1 mA 2.5 3.5 V
V
OL
Low-level output voltage V
ID
= –0.2 V, I
O
= 20 mA 0.35 0.5 V
I
I
In
p
ut current
V
CC
= 0 to 5.5 V,
V
I
= 10 V 1.1 3.25
mA
I
I
Inp
u
t
c
u
rrent
CC
,
See Note 4
V
I
= –10 V –1.6 –3.25
mA
I
OS
Short-circuit output current
§
V
O
= 0, V
ID
= 0.2 V –40 –75 –100 mA
I
CC
Supply current V
ID
= –0.5 V, No load 35 50 mA
†
All typical values are at V
CC
= 5 V, T
A
= 25°C.
‡
The algebraic convention, in which the less positive (more negative) limit is designated as minimum, is used in this data sheet for threshold levels
only.
§
Only one output should be shorted at a time, and duration of the short circuit should not exceed one second.
NOTES: 3. The expanded threshold parameter is tested with a 500-Ω resistor in series with each input.
4. The input not under test is grounded.
switching characteristics, V
CC
= 5 V, T
A
= 25°C
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
t
PLH
Propagation delay time, low- to high-level output
C
L
=30
p
F See Figure 1
15 25 ns
t
PHL
Propagation delay time, high- to low-level output
C
L
=
30
pF
,
See
Fig
u
re
1
13 25 ns
