ZHCS003 第 页，共 105 页
5
CC1100
10.6 PATABLE 存取.......................................................................................32
11 微控制器接口和引脚配置..........................................................................32
11.1 配置接口 ................................................................................................32
11.2 一般控制和状态引脚 ..............................................................................33
11.3 可选无线控制特性 .................................................................................33
12 数据速率编程 ...........................................................................................34
13 接收机信道滤波器带宽 .............................................................................34
14 解调器、符号同步器与数据判定...............................................................35
14.1 频率偏移补偿.........................................................................................35
14.2 位同步 ...................................................................................................36
14.3 字节同步................................................................................................36
15 数据包处理硬件支持.................................................................................36
15.1 数据白化................................................................................................37
15.2 数据包格式 ............................................................................................38
15.3 接收模式下的数据包滤波.......................................................................40
15.4 发送模式下的数据包处理.......................................................................41
15.5 接收模式下的数据包处理.......................................................................42
15.6 固件中的数据包处理..............................................................................42
16 调制格式...................................................................................................43
16.1 频移键控................................................................................................43
16.2 最小转换键控.........................................................................................44
16.3 振幅调制................................................................................................44
17 接收信号限定符和链路质量信息...............................................................44
17.1 同步字限定符.........................................................................................45
17.2 前导质量阈值 (PQT) .............................................................................45
17.3 RSSI ......................................................................................................46
17.4 载波监听 (CS).......................................................................................47
17.5 空闲信道评估 (CCA)
.............................................................................49
17.6 链路质量指示器 (LQI) ...........................................................................50
18 交错前向纠错 ...........................................................................................50
18.1 前向纠错 (FEC) ....................................................................................50
18.2 交错.......................................................................................................51
19 无线控制...................................................................................................51
19.1 上电启动序列.........................................................................................52
19.2 晶体控制................................................................................................54
19.3 稳压器控制 ............................................................................................54
19.4 有源模式................................................................................................54
19.5 无线唤醒 (WOR)
...................................................................................55
19.6 定时........................................................................................................57
19.7 RX 终止定时器 ......................................................................................57
20 数据 FIFO................................................................................................58
21 频率编程...................................................................................................60
22 VCO ..........................................................................................................61
