CC2652R7 SimpleLink™ Multiprotocol 2.4 GHz Wireless MCU
1 Features
• Microcontroller
– Powerful 48-MHz Arm
®
Cortex
®
-M4F processor
– EEMBC CoreMark
®
score: 148
– 704KB of in-system programmable flash
– 256KB of ROM for protocols and library
functions
– 8KB of cache SRAM (alternatively available as
general-purpose RAM)
– 144KB of ultra-low leakage SRAM. The SRAM
is protected by parity to ensure high reliability of
operation.
– 2-Pin cJTAG and JTAG debugging
– Supports over-the-air upgrade (OTA)
• Ultra-low power sensor controller with 4KB of
SRAM
– Sample, store, and process sensor data
– Operation independent from system CPU
– Fast wake-up for low-power operation
• TI-RTOS, drivers, bootloader, Bluetooth
®
5.2 Low
Energy controller, and IEEE 802.15.4 MAC in
ROM for optimized application size
• RoHS-compliant package
– 7-mm × 7-mm RGZ VQFN48 (31 GPIOs)
• Peripherals
– Digital peripherals can be routed to any GPIO
– Four 32-bit or eight 16-bit general-purpose
timers
– 12-bit ADC, 200k samples per second, 8
channels
– Two comparators with internal reference DAC
(one continuous time, one ultra-low power)
– Programmable current source
– Two UART
– Two SSI (SPI, MICROWIRE, TI)
– I
2
C
– I
2
S
– Real-time clock (RTC)
– AES 128- and 256-bit crypto accelerator
– ECC and RSA public key hardware Accelerator
– SHA2 Accelerator (full suite up to SHA-512)
– True random number generator (TRNG)
– Capacitive sensing, up to 8 channels
– Integrated temperature and battery monitor
• External system
– On-chip buck DC/DC converter
• Low power
– Wide supply voltage range: 1.8 V to 3.8 V
– Active mode RX: 7.1 mA
– Active mode TX 0 dBm: 7.6 mA
– Active mode TX 5 dBm: 9.9 mA
– Active mode MCU 48 MHz (CoreMark):
3.87 mA (81 μA/MHz)
– Sensor controller, low-power mode, 2 MHz,
running infinite loop: 30.1 μA
– Sensor controller, active mode, 24 MHz,
running infinite loop: 808 μA
– Standby: 1.15 µA (RTC on, 144KB RAM and
CPU retention)
– Shutdown: 151 nA (wakeup on external events)
• Radio section
– 2.4 GHz RF transceiver compatible with
Bluetooth 5.2 Low Energy and earlier LE
specifications and IEEE 802.15.4 PHY and
MAC
– Excellent receiver sensitivity:
-100 dBm for 802.15.4 (2.4 GHz),
-104 dBm for Bluetooth 125-kbps (LE Coded
PHY)
– Output power up to +5 dBm with temperature
compensation
– Suitable for systems targeting compliance with
worldwide radio frequency regulations
• EN 300 328, (Europe)
• EN 300 440 Category 2
• FCC CFR47 Part 15
• ARIB STD-T66 (Japan)
• Wireless protocols
– Thread, Zigbee
®
, Bluetooth
®
5.2 Low Energy,
IEEE 802.15.4, IPv6-enabled smart objects
(6LoWPAN), Wi-SUN
®
, proprietary systems,
SimpleLink
™
TI 15.4-stack (2.4 GHz), and
dynamic multiprotocol manager (DMM) driver.
• Development Tools and Software
– CC26x2R LaunchPad™ Development Kit
– SimpleLink™ CC13x2 and CC26x2 Software
Development Kit (SDK)
– SmartRF
™
Studio for simple radio configuration
– Sensor Controller Studio for building low-power
sensing applications
2 Applications
• 2400 to 2480 MHz ISM and SRD systems
1
with down to 4 kHz of receive bandwidth
• Building automation
– Building security systems – motion detector,
electronic smart lock, door and window sensor,
garage door system, gateway
– HVAC – thermostat, wireless environmental
sensor, HVAC system controller, gateway
1
See RF Core for additional details on supported protocol standards, modulation formats, and data rates.
ADVANCE INFORMATION
CC2652R7
SWRS253 – MAY 2021
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. ADVANCE INFORMATION for preproduction products; subject to change
without notice.
