CC2651P3 SimpleLink™ Single-Protocol 2.4 GHz Wireless MCU
With Integrated Power Amplifier
1 Features
Wireless microcontroller
• Powerful 48-MHz Arm
®
Cortex
®
-M4 processor
• 352KB flash program memory
• 32KB of ultra-low leakage SRAM
• 8KB of Cache SRAM (Alternatively available as
general-purpose RAM)
• Programmable radio includes support for 2-
(G)FSK, 4-(G)FSK, MSK, Bluetooth® 5.2 Low
Energy, IEEE 802.15.4 PHY and MAC
• Supports over-the-air upgrade (OTA)
Low power consumption
• MCU consumption:
– 2.91 mA active mode, CoreMark
®
– 61 μA/MHz running CoreMark
– 0.8 μA standby mode, RTC, 32KB RAM
– 0.1 μA shutdown mode, wake-up on pin
• Radio Consumption:
– 6.4 mA RX
– 7.1 mA TX at 0 dBm
– 9.5 mA TX at +5 dBm
– 22 mA TX at +10 dBm
– 101 mA TX at +20 dBm (7x7 package)
Wireless protocol support
• Zigbee®
• Bluetooth® 5.2 Low Energy
• SimpleLink™ TI 15.4-stack
• Proprietary systems
High performance radio
• -104 dBm for Bluetooth® Low Energy 125-kbps
• Output power up to +20 dBm with temperature
compensation
Regulatory compliance
• Suitable for systems targeting compliance with
these standards:
– ETSI EN 300 328, EN 300 440 Cat. 2 and 3
– FCC CFR47 Part 15
– ARIB STD-T66
MCU peripherals
• Digital peripherals can be routed to any GPIO
• Four 32-bit or eight 16-bit general-purpose timers
• 12-bit ADC, 200 kSamples/s, 8 channels
• 8-bit DAC
• Analog Comparator
• UART, SSI, I
2
C, I
2
S
• Real-time clock (RTC)
• Integrated temperature and battery monitor
Security enablers
• AES 128-bit cryptographic accelerator
• True random number generator (TRNG)
• Additional cryptography drivers available in
Software Development Kit (SDK)
Development tools and software
• LP-CC2651P3 Development Kit
• SimpleLink™ CC13xx and CC26xx Software
Development Kit (SDK)
• SmartRF™ Studio for simple radio configuration
• SysConfig system configuration tool
Operating range
• On-chip buck DC/DC converter
• 1.8-V to 3.8-V single supply voltage
• -40 to +105°C
Package
• 7-mm × 7-mm RGZ VQFN48 (26 GPIOs)
• 5-mm × 5-mm RKP VQFN40 (18 GPIOs)
• RoHS-compliant package
CC2651P3
SWRS257 – MARCH 2022
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
