TS3DV520E
www.ti.com
............................................................................................................................................................... SCDS240B – JUNE 2007 – REVISED MAY 2009
5-CHANNEL DIFFERENTIAL 10:20 MULTIPLEXER SWITCH
FOR DVI/HDMI APPLICATIONS
• Compatible With HDMI v1.2a (Type A) DVI 1.0 • Rail-to-Rail Switching on Data I/O Ports
High-Speed Digital Interface (0 to 3.6 V)
– Wide Bandwidth to support throughput of • V
CC
Operating Range From 3 V to 3.6 V
over 1.65 Gbps (Data rate 1.9 Gbps Typ)
• Latch-Up Performance Exceeds 100 mA Per
– Serial Data Stream at 10 × Pixel Clock Rate JESD 78, Class II
– Supports All Video Formats up to 1080p • ESD Performance Tested
and SXGA (1280 × 1024 at 75 Hz)
– 14-kV Human-Body Model Per JESD 22
– Total Raw Capacity 4.95 Gbps (Single Link) (A114-B, Class II)
– HDCP Compatible – 7.5-kV Contact Discharge Per IEC 61000-4-2
• Compatible with SXGA Video Display formats
up to 1080P (1280 × 1024 at 75Hz)
• DVI/HDMI Signal Switching
• Low Crosstalk (X
TALK
= – 37 dB Typ)
• Differential DVI, HDMI Signal Multiplexing for
• Low Bit-to-Bit Skew (t
sk(o)
= 0.1 ns Max)
Audio/Video Receivers and High-Definition
• Low and Flat ON-State Resistance
Televisions (HDTVs)
(r
on
= 4 Ω Typ, r
on(flat)
= 0.5 Ω Typ)
• Low Input/Output Capacitance
(C
ON
= 8 pF Typ)
The TS3DV520E is a 20-bit to 10-bit multiplexer/demultiplexer digital video switch with a single select (SEL)
input. SEL controls the data path of the multiplexer/demultiplexer. The device provides five differential channels
for digital video signal switching.
This device provides low and flat ON-state resistance (r
on
) and excellent ON-state resistance match. Low
input/output capacitance, high bandwidth, low skew, and low crosstalk among channels make this device suitable
for various digital video applications, such as DVI and HDMI.
Voltage on the SEL pin should be less or equal to V
CC
, even in the power-down mode (V
CC
= 0 V).
ORDERING INFORMATION
T
A
PACKAGE
(1) (2)
ORDERABLE PART NUMBER TOP-SIDE MARKING
TQFN – RHU Reel of 2000 TS3DV520ERHURG4 SD520E
– 40 ° C to 85 ° C
QFN – RUA Reel of 2000 TS3DV520ERUAR SD520E
(1) Package drawings, thermal data, and symbolization are available at www.ti.com/packaging .
(2) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI
website at www.ti.com .
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date.
Copyright © 2007 – 2009, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
