安森美半导体ESD保护器件PACUSB-D1-D 数据手册pdf,安森美半导体ESD保护器件PACUSB-D1-D 数据手册
PACUSB-D1/D2/D3 Ordering Information PART NUMBERING INFORMATION Standard Finish Lead-free Finish Ordering part Ordering part Ins R1 Value Package Number Part Marking Number Part Marking 15g SOT23-5 PACUSB-D2Y5 UDF2 PACUSB-D2Y5R DE2R 22g PACUSB-D3Y5 UDF3 PACUSB-D3Y5R DEBR 33g PACUSB-D1Y5 UDF1 PACUSB-D1Y5R DE1R 15g SC70-5PACUSB-D2YB5 DF2 PACUSB-D2YB5R F2R 22g PACUSB-D3YB5 DF3 PACUSB-D3YB5R F3R 339 PACUSB-D1YB5 DE1 PACUSB-D1YB5R F1R Note 1: Parts are shipped in Tape& reel form unless otherwise specified Specifications ABSOLUTE MAXIMUM RATINGS ARAMETER RATING UNITS Storage Temperature Range 65to+150 Power Dissipation per Resistor 100 Package Power Dissipation 200 Voltage on any pin(DC) STANDARD OPERATING CONDITIONS PARAMETER RATING UNITS Operating temperature 40to+85 Rev.2Page3of10www.onsemi.com PACUSB-D1/D2/D3 ELECTRICAL OPERATING CHARACTERISTICS (SEE NOTE SYMBOL PARAMETER CONDITIONS MIN TYP MAXUNITS R1 Resistance of R1 Resistor T.=25° 12 18 (PACUSB-D2Y5/Y5R,-D2YB5/YB5R) R1 Resistance of r1 resistor T=25° 17.6 22 264 (PACUSB-D3Y5/Y5R, -D3YB5/YB5R) R1 Resistance of r1 resistor T=25°C 26433 396 (PACUSB-D1Y5/Y5R,-D1YB5/YB5R) R2 Resistance of r2 resistor T=25°C 15 ko TCR Temperature Coefficient of Note 1 1300 opm/o Resistance C C1 Capacitance of C1 Capacitor 0VDC: 30 mVAC: 1MHz: 25C 37.6 47 564 F 2.5 VDC: 30 mVAC: 1MHz: 25 C 25.6 3238. pF TOL Matching Tolerance of C1 Capacitors 1MHZ; 25.C 2 LEAK Diode Leakage Current to GND Measured at33VDC,25° 100 nA Diode Reverse Bias Voltage Lo=10μuA;T=25°c 5.5 ig Positive Clamp =10mA:T=25° 566. 9.0 Negative Clamp oan =10mA; TA=25C 0.4 0.8 15 ESD In-system ESD Withstand Voltage MIL-STD-883D, Method 3015 kV (HBM) Pins 1, 3: notes 2 and 3 Pins 4. 5: Note 2 20 lEC 61000-4-2 Contact Discharge Pins 4. 5: Notes 2 ±15 KV Clamping voltage under ESD MIL- STD-883D. Method 3015 12 discharge +8kV: note 4 MIL-STD-883D Method 3015 8k, Note 4 Note 1: Electrical operating characteristics guaranteed over standard operating conditions unless specified otherwise Note 2: ESD voltage applied to pins with respect to GND, one at a time; unused pins are left open Note 3: Pins 1 and 3 are not connected to the USB port connector, and therefore are not exposed to external ESD hazards Thus, they do not require the high ESD protection levels provided for pins 4 and 5 Note 4: ESD Clamping voltage is measured at the opposite end of R1 from the pin to which the ESd discharge is applied (e. g, if ESD is applied to pin 6, then the clamping voltage is measured at pin 1) Rev.2Page4of10www.onsemi.com PACUSB-D1/D2/D3 Performance Information Capacitance Vs. Voltage The C1 capacitance value as a function of dc voltage across it is presented in Figure 1. The curve is normalized to a capacitance of 1.0 capacitance units at 2.5 VDC 16 0.6 02 DC Vo ltage Figure 1. Diode Capacitance vs. Dc Voltage(Normalized Insertion Loss Vs Frequency Characteristics lag KAJ tn REF 0 3B =2.167d d04 1心 C43 dB 10D 飘E口LEcY4Ml Figure 2. Insertion LOSs Vs Frequency Performance Curve, PACUSB-D1SOT23-6) Rev.2Page5of10www.onsemi.com PACUSB-D1/D2/D3 Performance Information(contd) s21199MA 3 uB/ 1:-1.2202 .B D山B 9 dB 本日79豆 62 cB .2U uB 03 tutu 1020 FRECJEMCY (MRES Figure 3. Insertion Loss vS Frequency Performance Curve, PACUSB-D2(SOT23 1 a us/ I=P C LH ‘:!as AO NHz B NH2 20 7c1 w 10D Ioc FHEQL∈ NGY IMH: Figure 4. Insertion Loss VS Frequency Performance Curve, PACUSB-D3 (SOT23-6) Rev.2Page6of10www.onsemi.com PACUSB-D1/D2/D3 Application Information The PACUSB-D1/D2/D3 provides a complete interface for a single downstream USB port typically found in computers and USB hubs. It integrates the series resistors(R1) and the 15k@2 pull-down resistors (R2) for both USB data lines(D+ and D-)as well as the capacitors to ground for EMI suppression Zener diodes provide ESD protection up to 15kv contact discharge per the IEC 61000-4-2 standard and protect the USB controller on both data lines The PACUSB-D1/D2/D3 should be placed on the PCB between the USB controller and the USB connector, as shown on the Connection Diagram, Figure 5 PACUSB-DnY5/Y5R,-DnYB5/YB5R R1 D 5 D+ R2 DOWN USB STREAM CONTR OLLER CONNECT OR R2 C1 D 3 D R1 Figure 5. Connection Diagram for PACUSB-D1/D2/D3 Devices To guarantee the best ESD and filtering performance, it is recommended to physically locate the Pacusb- D1/D2/D3 close to the USB connector. Also, the trace lengths between the pacusb-D1/D2/D3 and the USB controller should be kept as short as possibl Rev.2Page7of10www.onsemi.com PACUSB-D1/D2/D3 Mechanical details PACUSB-D1/D2/D3 devices are packaged in SOT23-5 and SC70-5 packages SOT23-5 Mechanical Specifications: Dimensions for PACUSB-D1/D2/D3 devices packaged in a 5-pin SoT23 package are presented below For complete information on the SoT23-5 package, see the California Micro Devices SoT23 Package Information document PACKAGE DIMENSIONS Package SOT23-5 (JEDEC name is Mo-178 TOP VIEW e Pins 5 Millimeters Inches Dimensions 4 Min Max Min Max E1E A 1.45 0.057 1 A1 0.00 0.15 0.000 0.006 b 0.30 0.50 0.012 0.020 SIDE VIEW 0.08 0.22 0003 0.009 D 2.75 3.05 0.108 0.120 E 2.60 3.00 0.102 0.118 A E1 1.45 1.75 0.057 0.069 0.95 BSC 0.0374BSC e1 1.90 BSC 00748BSC END VIEW 0.30 0.60 002360.024 L1 0 60 REF 0.024REF per tape 3000 pieces and reel Controlling dimension millimeters This is an approximate amount which may vary Package Dimensions for SoT23-5 Rev.2Page8of10www.onsemi.com PACUSB-D1/D2/D3 Mechanical Details(continued) SC70-5 Mechanical Specifications Dimensions for PACUSB-D1/D2/D3 devices packaged in a 5-pin SC70 package are presented below For complete information on the sc70-5 package, see the california micro Devices SC70 Package Information document PACKAGE DIMENSIONS TOP VIEW SC705 Package (JEDEC name is Mo-203 Issue A) Pins 5 Millimeters E HE Dimensions Min Max 0.80 1.10 B A1 0.00 0.10 SIDE VIEW A2 0.70 1.00 D B 0.15 0.30 0.08 0.25 A2 A D 185 2.25 E 1.15 1.35 0. 65 BSC END VIEW HE 2.00 2.40 L 0.26 0.46 #/ bag 1000 pieces tape and reel 3000 pieces Package Dimensions for SC70-5. This is an approximate amount which may vary Rev.2Page9of10www.onsemi.com PACUSB-D1/D2/D3 ON Semiconductor and Nare registered trademarks of Semiconductor Components Industries, LLC(SCILLC). SCILLC reserves the right to make changes without further notice to any out of the application or use of any product or circuit, and specifically disclaims any and all liability, indluding without limitation special, consequential or incidental damages. " Typical parameters which may be provided in SCILLC data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All operating parameters, including "Typicals must be validated for each customer application by customer's technical experts. SCILLC does not convey any license under its patent rights nor the rights of others. SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applicaticns intended to SCILLC products for an any other application in which the failure of the SCilla product could create a situation where personal injury or death may occur. Should Buyer purchase or support or sustain life use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold SCILLC and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly ar indirectly, any claim of personal injury or death associated witn such unintended or unauthorized ren if such claim alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner PUBLICATION ORDERING INFORMATION LITERATURE FULFILLMENTS N. American Technical Support: 800-282-9855 onSemiconductorwebsitewww.onsemi.com Literature Distribution Center for ON Semiconductor Toll Free USA/Canada P O. Box 5163. Denver Colorado 80217 USA Europe, Middle East and Africa Technici OrderLiteraturehttp://www.onsemi.com/crderlit Phone: 303-675-2175 or 800-344-3860 Toll Free USA/Canada support Fax: 303-675-2176 or 800-344-3867 Toll FrCc USA/Canada Phone:421337902910 For additional information, please cantact yaur local Email: orderlit onsen com Japan Customer Focus Center Sales Representative Phono:81357733850 Rev.2Page10of10www.onsemi.com

...展开详情
试读 10P 安森美半导体ESD保护器件PACUSB-D1-D 数据手册.pdf
立即下载 低至0.43元/次 身份认证VIP会员低至7折
一个资源只可评论一次,评论内容不能少于5个字
您会向同学/朋友/同事推荐我们的CSDN下载吗?
谢谢参与!您的真实评价是我们改进的动力~
关注 私信
上传资源赚钱or赚积分
最新推荐
安森美半导体ESD保护器件PACUSB-D1-D 数据手册.pdf 15积分/C币 立即下载
1/10
安森美半导体ESD保护器件PACUSB-D1-D 数据手册.pdf第1页
