新箭:XJK-XG1K无热再生吸附式干燥机控制器说明书.pdf

所需积分/C币:25 2019-09-18 16:39:44 622KB PDF
26
收藏 收藏
举报

新箭:XJK-XG1K无热再生吸附式干燥机控制器说明书pdf,XJK-XG1K 型无热再 生吸附式干燥机控 制器是无热再生吸 干机控制器的新成 员。产品在功能上保 留了原无热吸干机 控制器的主要功能, 在时序控制上做了 改进,让用户在设置 时能更清楚。另外控制器内置电源,并采用了文本显示屏外壳。具有维护方便,安装简单, 美观大方的特点。
简介 XJK-XG1K型无热再 出气Am 生吸附式干燥机控 XJK-XG1K型 无热再生吸干机控制器 制器是无热再生吸 Heatless Desiccant Air Dryer Controlli 合 千机控制器的新成 员。产品在功能上保 合A B 再生 留了原无热吸干机 控制器的主要功能, 启动 在时序控制上做了 改进,让用户在设置 时能更清楚。另外 图1 Figure 1 控制器内置电源,并采用了文本显示屏外壳。具有维护方便,安装简单 美观大方的特点,见图1 XJK-XGIK is the newest member of heatless desiccant air dryer controller. It reserves the main function of old heatless desiccant air dryer controller, and improve some parameter definition to help user understand their meaning easily. Otherwise, there has a SPs(Swicht Power Supply) and the controller has an encloser. So maintenance is convenient, installation is easy 主要功能 1.设置功能:在设置状态下,可通过两个按钮设置各项参数。 2.控制功能:在运行状态下,四个继电器按设置的工作时间值控制吸附 式千燥机A、B两塔的吸附和再生工作 3.显示功能:四位数码管显示。 Set: use two buttons to modify each parameter 2. Control: in running mode, four relays in the controller control the drying and regeneration work of tower A and tower B, based on the preset parameters 3. Display: use 4 pieces of lEd nixie tubes to display the value 技术参数 1.电源电压:220V(+10%~-15%)50Hz 2.输出容量:继电器输出,继电器触点电压AC220V或DC24V,输出电流 AC220V/DC24V感性负载0.8A,阻性负载2A; 延时精度:工作周期的±3%; 4.使用条件 a)海拔≤2000米; b)工作环境温度:-25℃~55℃; c)环境湿度≤95%,无冷凝; d)周围空气中无明显的灰尘、酸、腐蚀性气体或物质。 1. Power supply: 220V(+10% 5%)50Hz 2. Output capability: relay output, the power of relay is AC220V or DC24V, the output current is 0. 8a (inductive load), the output current is 2A (resistive load) 3. Time precision: the error should less than 3% in every work cycle 4. Use condition: a) Height above sea level<2 000 m b) Ambient temperature:-25℃~55℃; c) Ambient relative humidity <95%, no condensation d) No dust, acidic, active gases or matter 四、参数设置 控制器分两个状态:设置状态、运行状态(包括待机状态)。将控制器 背面右下方的拨动开关拨向左侧,控制器即处于设置状态。设置完成将拨 动开关拨向右侧,为待机状态。按下启动按钮,为运行状态 The Controller has two states: set mode, running mode (include waiting state). Set the bottom right corner switch in the bake of controller to left-hand, the controller enters into set mode. After completing the set, put the switch to right-hand, the controller enters into waiting state. Press the start button, enters into running mode 参数说明 参数号参数名称 参数含义 没定范围 Code Name Meaning Set range 吸附时间 干燥机A塔或B塔的工作时间 1~999s Drying time the drying time of tower a or tower B 再生延时 等待设定时间后,将A塔或B塔产生的干 燥气体用于B塔或A塔千燥剂的千燥 Delay time of 1~60 After the preset time use dried air to regeneration regenerate the desiccant in tower A or tower B 再生时间 A塔或B塔干燥剂的干燥时间 Regeneration The drying time of reactiving desiccant in1-999s time tower a or tower b 均压时间 A塔及B塔进气阀同时打开的时间 Pressure The time for inlet vavle of tower A and s balance time tower B open to sure the pressure is equal 0表示正阀(4个常闭阀),1表示反阀 (2个排气阀为常闭,2个进气阀为常 控制模式开),2表示对角阀 0 means the system use four NC valves 1 System mode means the system equip two NC valves for outlet valve and two no valves for inlet valve:2 means cross 参数号参数名称 参数含义 设定范围 C ode Name Meaning Set range 时间显示 0表示正计时,1表示倒计时 0 means cumulate display drying time, 1 0 Time display means countdown display drying time 注:吸附时间(t1)须≥再生延时时间(t2)+再生时间(t3)+均压时 间(t4)。 Note: drying time(tI)should be delay time of regeneration(t2 )+ regeneration time(t3)+ pressure balance time(t4) 为防止用户参数设置错误,本控制器能自行判断,限制各参数的上限 值 设置参数值 在设置状态下,按面板上的“启动”按钮(此时的功能是参数选择), 选择参数号;按动面板的“停止”按钮,修改参数值。参数值只能递增, 到上限后,重新从下限循环递增 In set mode, press the START button to choose the parameter code, press the Stop, button to modify the value of parameter note that the value can be increased by degrees, up the upper limit, then return to the lower limit 从左到右数码管的第一位显示“1”,表示目前设定的是第一号参数; 其余位显示参数设定值。按动“停止”按钮,修改参数值 When the first bit of LEd nixie tube from left to right displays l,means the current parameter is the first parameter, the other LEd nixie tubes displays the preset value. Press "StOP button to modify 在设定时,按住“停止”按钮超过3秒钟,设定值将快速增加,而断 续按动时则每次加1 In set mode, press the 'StoP button over 3 seconds, the value decrease quickly. Press spasmodically the value decrease l each time 没定完毕,将控制器背面右下方的拨动开关拨向右侧,进入待机状态 同时设定值被写入EPR0M储存起来,即使断电后仍能保留所设的参数值 After completing set, set the bottom right corner switch in the bake of controller to right-hand, and the setting will be saved into E PROM. These data can be kept for later use even if power off. 五、使用 ●上电 上电(AC20V),“运行”、“停止”灯同时亮一下,完成控制器自检 自检完成,“停止”灯常亮。控制器即进入默认待机状态 Energize the controller, the 'run'and'stop' lamp will light to show the controller is self-checking. After completing, the 'stop' lamp is lighting continuous, and the controller enter into waiting mode 启动 在待机状态下,按下“启动/+”按钮,“运行”指示灯亮。控制器按 图2的时序工作。四个继电器YⅥ1~YV4(ⅣⅥ1:A塔吸附、YV2:A塔再生 YV3:B塔吸附、YV4:B塔再生)相继动作,红、绿色发光管指示工作状 态,数码管倒计时或正计时显示吸附时间。每次启动,A、B塔轮换先工作, 以保证A、B塔工作时间一致, In waiting state, press "START button, and the run?lamp will light, the controller control the work of four valves. See the figure 2 for details. The four relays YVI-Yv4(YVI: Tower A inlet, YV2: Tower A outlet, YV3: Tower B inlet, YV4: Tower B outlet)open or close based on the preset value, the red and green indicator lights to show the work state, The tower a and tower b will work first in turn when every start, to sure the work-time of each tower is equal 时序工作图 见图2 See the figure 2 正阀结构 A塔吸附B塔再生 t4 t4 B塔吸附A塔再生 再生延时t2 YVI 畈附时间t1 /再生时间t3 期压 均压 再生延时t2 Y4 /,再生时间t3 暇附时间t1 When the system use four nC valves Tower A drying, tower B regenerate ower B drying, tower A regen erate 4 t 4 imet Drying time t1/ Regeneration time t3 YV2 Pressure balance time 4 Pressure balance time Del ay time t2 Drying time ft 反阀结构: A塔吸附B塔再生 B塔吸附A塔再生 4 YI 吸附时间t1 L再生时间t3 Y2 再生延时t2 均压 均压t4 吸附时间t1 Y3 再生延时t2 Y4 再生时间t3 When the system use two NC valves and two No valves Tower a drying, Tower B regenerate t4 Tower B drying, Tower A regenerate t4 Drying time t 1 Regeneration time t3 V2 Delay time t2 Pressure balance time 4 Pressure bg lance time YV3 Delay time t 2 Y4 L Regenerate time t3 Drying timetl ●停止 按“停止”按钮则停止工作,“停止”指示灯亮。继电器全部释放, 控制器复位 Press the ', button to stop the controller, the 'stop 'lamp will light and all the relays are released 六、结构尺寸 控制器采用文本显示屏外壳,安装尺寸为:152×102×55。 控制柜尺寸:320×240×100 152mm XK-XG1K安装开孔 The controller has an enclosure. fix hole size is 152 x 102x 55 And the size of cabinet is320×240×100. 七、安装接线 控制器背面各端子定义: The definition of each plug: KJK-XGK控制器背面 设置/运行 F[A吸A再吸B再 控制柜内的端子接线方式如下 The definition of connection port as following

...展开详情
