汇川-NICE5000电梯一体化控制器用户手册-英文版本号:V1.1pdf,
Notes The drawings in the manual are sometimes shown without covers or protective guards Remember to install the covers or protective guards as specified first, and then perform operations in accordance with the instructions The drawings in the manual are shown for description only and may not match the product you purchased The instructions are subject to change, without notice, due to product upgrade, specification modification as well as efforts to increase the accuracy and convenience of the manual Contact our agents or customer service center if you need a new user manual or have problems during the use .Email:UM@inovance.cn NICE5000 User Manual Introduction Introduction 1. Product overview The NICE5000 integrates functions of the elevator controller and high-performance vector control AC drive. With the controller as the core, the elevator drive control system is constructed 2. Product features The NICE5000 has the following major features More advanced technology 1)Integration of drive and control, which makes system configuration simpler and reduces peripheral wiring and the cost 2) Distance-based direct travel ride, n curves generated automatically, bringing good riding comfort 3 Support for parallel control of two elevators 4) No-load-cell startup for various types of encoders, ensuring smooth startup 5 Drive for both synchronous and asynchronous motors 6) High-performance vector control, achieving good motor performance and riding comfort 7) Use of CANbus and Modbus communication, reducing the quantity of traveling cables 8) Remote monitoring, making the states of elevators connected to the network be viewed clearl Easier use 1)Compact structure, requiring only a small equipment room or even no equipment room 2) Parameters easy to memorize, support for commissioning inside the car, making commissioning convenient 3 Multiple commissioning tools, including keypad, operation panel, host computer monitoring software, making inspection, commissioning and maintenance of the elevator easy Safer running 1) Multiple security protections, compliant with the GB-7588-2003 standard, CE certificated 2) Passing the EU MP lab test, proved to be compliant with the EMC requirements 3 Professional drive manufacturing process, electrical components moisture-proof, dustproof, and anti-OXidation 4) Lightning absorption and anti-mains voltage fluctuation design for the circuit 5) Password security with corresponding operation rights, implementing protection of elevator operations Introduction NICE5000 User Manual 6) Redundancy of hardware and software, handling of fault signals with highest priority preventing accident hazard 7) Support for open-loop low speed running More friendly operation 1)Easy operation and maintenance 2) Built-in real-time clock, which provides time-based services, facilitating intelligent floor service management 3) Detailed fault records 4 Flexible modular optional parts 3. Function list of the nice5ooo Common Running Functions Full collective n automatic running or attendant state this function enables the elevato selective to respond both car calls and hall calls. Passengers at any service floor can call the elevator by pressing the up call button and down call button Down collective In automatic running or attendant state, the elevator responds only to hall selective control down calls besides car calls Door open time The system automatically determines different door open time for door open for call, command, protection, or delay according to the set door setting open holding time Door open holding In automatic running state, passengers can press the door open button in the car to delay door open to facilitate goods to be moved in or out. Door machine Users can set the required service floors of the door machines service floor setting Door pre-close b During door open holding in automatic running state, passengers can the door close button press the door close button to close the door in advance, which improves the efficiency hen the door fails to close within the set time due to the action of the Forced door close light curtain or safety edge, the elevator enters the forced door close state, closes the door slowly, and gives a prompt tone Door control function You can set whether the system keeps outputting commands after door open limit and door close limit based on the type of the door machine Floor number display The system supports display of floor numbers in combinations of numbers setting and letters, which meets the requirements of special conditions Light curtain signal I the door is blocked by stuff during door close, the light curtain acts and the elevator opens the door. this function is invalid in fire emergency judgment state Auxiliary operation An optional auxiliary operation box that has the same functions as the main operation box is available Independent control of the front door and depends on your requiremen car, automatic control on the two doors When there are two doors for back door NICE5000 User Manual Introduction If the door lock is not applied after the elevator performs door close for a Repeat door close certain time, the elevator automatically opens the door and then closes the door again Independent When the main and auxiliary operation boxes are configured, they can command independently control door open/close according to the commands in automatic running state Voice announcement The elevator automatically announces information such as the running direction and next arriving floor during running Leveling accuracy The leveling accuracy can be adjusted by setting parameters adjustment Auto-leveling The systems implements automatic accurate leveling based on the floor pulse counting and up/down leveling feedback signals Response at The system allows the elevator to automatically respond to calls from the acceleration service floors during acceleration Idle elevator In automatic running state, the elevator automatically returns to the set returning to base parking floor and waits for passengers if there is no car call or hall call within the set time Landing at another If the door open time exceeds the door open protection time but the door floor open limit signal is still inactive, the elevator closes the door and then automatically runs to the next landing floor. The system reports fault E55 Cancellation of Passengers can press the button consecutively twice to cancel wrong wrong calls calls You can enable or disable the system service for certain floors flexibly Service floor setting based on actual requirements Time-based floor You can flexibly set the time periods and corresponding service floors or service select the service floors by using the service floor switchover switch The elevator does not respond to any call, and the door needs to Independent running be closed manually. In the case of group control, the elevator runs independently out of the group control system In attendant state, the running of the elevator is controlled by the Attendant running attendant Low-speed self- When the elevator is in non-inspection state and stops at non-leveling rescue area, the elevator automatically runs to the leveling area at low speed if the safety requirements are met, and then opens the door The systems perform self-check on the elevator periodically and record Periodic self-check error information within the set time, ensuring reliability and security or o in standby state elevator running Waiting floor Vhen the elevator arrives at a floor the hall indicator of this floor indicator becomes on, indicating that the elevator has arrived Car arrival gong After the elevator arrives at the destination floor, the ctB gives a prompt tone Hall arrival forecast When the elevator will arrive at the destination floor soon the Mctc- indicator HCB-B outputs a signal to turn on hall arrival forecast indicator After the elevator will arrive at the destination floor soon the mctc- Hall arrival gong HCB-B outputs a signal to turn on the hall arrival gong Introduction NICE5000 User Manual Hall l/O extension If the hall w/O terminals are not sufficient, more terminals can be provided function by using an HCB-B board Car l /O extension If the car 1/0 terminals are not sufficient, more terminals can be provided function by using an HCB-B board The system can automatically identify whether a hall call button is stuck Button stuck check and cancel the stuck call, preventing the condition that the elevator cannot close and run due to stuck hall calls Automatic startup The system automatically implements startup torque compensation based torque compensation on the current car load, achieving smooth startup and improving the riding comfort The system automatically calculates and generates the running cury Direct travel ride based on the distance, enabling the elevator to directly stop at theves leveling position without creeping Automatic The system automatically calculates the optimum speed curve compliant generation of with the human-machine function principle based on the distance, without optimum curve being limited by the number of curves or short floor Service suspension When the elevator cannot respond to hall calls, the corresponding output terminal outputs the service suspension signal Running times In automatic running state, the system automatically records the running recording times of the elevator Rul The system automatically records the accumulative power-on time recording working hours, and working days of the elevator Switchover of The main parking floor can be switched over by operating the related parking floor switch or the switchover time is reached Automatic door If the system detects that the door lock circuit is abnormal during door open upon door lock open/close, the elevator automatically opens and closes the door again abnormality and reports a fault after the set door open/close times is reached VIP service The elevator first directly runs to the vip floor and provides services for special persons Specified elevator preferred The specified elevator is preferred to respond to calls of specified floors When the elevator is waiting at the leveling position, if there is a call at Disability service this floor from the disability operation box, the door open holding time is prolonged. It is the same for the back door When the car is full-loaded in automatic running state the elevator Full-load direct does not respond to hall calls from the passing floors. These halls calls however, can still be registered and will be executed at next time of running running(in the case of single elevator)or by another elevator(in the case f parallel/group control) Overload protection When the car load exceeds the rated elevator load, the elevator alarms and stops running. Elevator abnormality The system performs protection in time at abnormality, guaranteeing protection elevator safet NICE5000 User Manual Introduction The system automatically records detailed information of faults, which Fault data recording helps improve the efficiency of maintenance and repair Inspection-related Functions Simple maintenance The 3-button keypad on the MCB provides the functions such as keypad commissioning the running floors and door open/close Commissioning and maintenance can be carried out only with easy Easy setting for setting commissioning and motor auto-tuning, slow-down switch detection and shaft detection maintenance automatic detection of elevator states, abnormality record, and periodic self-check Operation box The operation panel can be connected to the system in the car for commIssIonIng elevator commissioning, which improves the commissioning efficiency Shaft auto-tuning is required before first-time automatic running. During Shaft auto-tuning shaft auto-tuning, the elevator runs from the bottom floor to the top floor at the inspection speed and automatically records all position signals in the shaft User-defined You can view the parameters that are modified and different from the parameter display default setting Inspection function selection The system provides multiple inspection functions for users to select After entering the inspection state, the system cancels automatic running Inspection running and related operations. You can press the up or down call button to make the elevator jog at the inspection speed With simple parameter setting, the syst btain the mote Motor auto-tuning parameters no matter whether the motor is with -load or without load Inertia identification The system automatically identifies the elevator inertia at startup and produces compensation, achieving smooth running Every time the elevator runs to the terminal floor, the system automatically Floor position checks and corrects the car position information based on slow-down intelligent correction switch 1, and eliminates over travel top terminal or bottom terminal with use of the slow -down switches Dual-speed for Considering inaccurate running control at high inspection speed but long inspection running time at low inspection speed, the system provides the dual-speed curve for inspection, which greatly improves the efficiency at inspection ndication state test Whether indications of system states can be tested Test function The system provides multiple test functions for users to select, improving selection test, acceptance, and maintenance efficiency The test running includes the fatigue test of a new elevator, car call floor Test running test, hall call test, and tests such as hall call response forbidden, door open/close forbidden, terminal floor limit switch shielded, and overload signal shielded Introduction NICE5000 User Manual Fire Emergency and Security Functions Returning to base floor at fire After receiving a fire emergency signal, the elevator does not respond to any call but directly runs to the fire emergency floor and waits emergency After the elevator enters the firefighter operation mode, door open/close Firefighter operation is implemented by the jog operation(optional) by using the door open and close buttons rather than automatically. In addition, the elevator responds to only car calls and only one call can be registered once After the security floor function is enabled, the security floor is used at Security floor 10: 00 p. m. to 6: 00 a. m, and the elevator runs to the security floor first every time, stops and opens the door, and then runs to the destination floor In automatic running state, when the elevator lock switch acts or the set Elevator lock elevator time is reached, the elevator cancels all registered calls, returns to the elevator lock floor, stops running, and turns off the lamp and fan in the car Forced stop at floor hen a floor is specified as the forced stop floor, the elevator stops at this floor at each time running Operation rights The system provides multiple levels of security passwords, each restricted based on corresponding to different operation rights, improving elevator operation s securit Troubleshooting Faults are classified into different levels based on the severity. Different based on fault level levels of faults are rectified using different methods The system detects the running state of the elevator in real time. If the Runaway prevention elevator speed exceeds the limit, the system immediately stops running of the elevator Automatic The system automatically identifies power failure and outputs the relay identification of signal for emergency evacuation automatic switchover to implement power failure emergency evacuation at power failure For the synchronous motor, when the power supply is interrupted, the system can perform automatic switchover between shorting stator braking mode and controller drive mode, implementing quick and stable self- Automatic running rescue power failure Shorting stator braking mode: Upon power failure, EPS is used, the motor stator is shorted, and the brake is automatically released, making the car move slowly under the effect of the weighing difference between the car and the counterweight Running direction self-identification at When the power supply is interrupted, the system can automatically power failure identify the current car load and determine the running direction Base flo After detecting a position abnormality, the system runs the elevator to verification each floor until reaching the terminal floor for verification, guaranteeing system Passenger unloading The system automatically determines the fault level If the safety running first upon fault itions are met, the elevator first runs to the leveling position to unload passengers 8 NICE5000 User Manual Introduction Interference degree judgment The system judges the degree of communication interference When the earthquake detection device acts and inputs a signal to the Earthquake system, the elevator lands at the nearest floor and stops running. After protection the earthquake signal becomes inactive and the fault is reset manually, the elevator restores to normal running current cancellation For the PMSM, after the elevator decelerates to stop, the holding current of the motor is cancelled in ramp mode, preventing abnormal noise during in ramp mode current cancellation The NICE5000 system supports not only three-phase 380 VAC but also Independent working single-phase 220 VAC to meet different applications of the power supply power supply system (such as 220 V UPS Automatic voltage The system detects the bus voltage and automatically adjusts the running identification speed of the elevator to adapt to the situation of insufficient power from power supply(such as EPS) This function is optional for the grot ol elevator system configured with the EPs device. When the EPS is used, the system automatically selects the elevator that is proper to run based on the preset parameters After the normal power supply restores, the system restores normal Intelligent distribution running of emergency power This function prevents power overload due to simultaneous running of supply(EPS multiple elevators when the eps is insufficient modification and peripheral parts are required T it is used, software Note: This function is not the standard function If Parallel/ Group Control and other Functions The system supports parallel control of two elevators and provides Parallel control multiple scheduling algorithms to meet requirements of different ustomers Dispersed waiting In parallel/group control, the elevators can wait at different floors If the parallel/group control exit switch of a certain elevator in a parallel Parallel/Group group control system is valid or the time for exiting the parallel/group control exit control is reached, the elevator exits parallel/group control and runs dependently. This does not affect normal running of the parallel/g control system Parallel/Group If an elevator in the parallelgroup control system cannot respond to control automatic calls in time due to faults, the elevator automatically exits the parallel/ group control system and runs independently. This does not affect normal running of the parallel/group control system The system automatically judges the number of passengers in the car Anti-nuisance and compares it with the number of registered car calls. If there are function all car calls. In this case, passengers need to register correct car callsels excessive car calls, the system determines that it is nuisance and can aga Prompt of non-door The system gives a prompt when the elevator stops at a non-door zone zone stop area due to faults 9
