m 后质 - rfT F R Since the establishment in 1993, Sfae has always held to the principle of Customer first, Best service"and set up 21 regional offices across China. SFAE provides professional automation engineering solutions, LV cabinet products and services to over 4,000 customers in areas such as CNC machine tools retrofitting, crane/hoisting machine, oil drilling machine, steel and metallurgy, test bed system, automobile manufacturing, Manufacturing Execution System(MES), Motion Control Information System(MCIS)and production machine. SFAE leaped into top 100 enterprises of China electric industry and rose up to the 74 place in 2007 from the 93 in 2006 Based on the experience of thousands of cabinets we have manufactured, control ca binet Department( CCAB)can provide customized control cabinets and specialized services in the industrial and civilian automation field We develop our business in CNC machines, production machines, hoist machines, petroleum drilling machines, metallurgy, auto manufacturing, transportation, logistics and wind power. Our products are widely used and play an essential role in factories, mines, automobile plants, water plants, airports and seaports in China. We own professional teams, knowing the siemens products well, having a special experience and an innovation spirit. We dedicate ourselves to control cabinets, providing the total solution from design, manufacture, commissioning and service to support the customers progressing and to strengthen their competence. We commit ourselves to set up a long partnership with the customer and we would like to come to the top with the customer together in the market 西门子控制电柜产品制造商 Siemens Control cabinet manufacturer P7-8 P9-10 P11-12 数控机床 生产机械 汽车制造 CNC Machine Tool Production machine Automotive Manufacturing P15-16 P17-18 P19-20 机场建设 风力发电 钢铁冶金 Airport Construction Wind power Steel and Metallurgy P23-24 P25-26 P27-28 石油钻机 管理体系 质量控制 Oil Drilling Machine Management system Quality Control 目录 Contents 西门子控制电柜产品 P1 Siemens control cabinet products 行业概览 P3 Industry Sectors Know-how 数控机床 ………P7 CNC Machine too P13-14 生产机械 P9 厂房建设 Production machine Plant Building 汽车制造 ……P11 Automotive Manufacturing 厂房建设………………………………………………P13 Plant Building w网w 机场建设 P15 Airport Construction 风力发电 P17 Wind power P21-22 钢铁冶金 P19 港口机械/起重机 Steel and Metallurgy Crane/Hoisting Machine 港口机械/起重机 P21 Crane/Hoisting Machine 石油钻机 P23 Oil Drilling machine 管理体系 P25 Management Syster 质量控制 P27 P29-30 客户资源… ··· P29 客户资源 Customer resources Customer Resources 西门子控制电柜产品 Siemens Control cabinet Products 数控柜 数控柜是每台机床最重要的电气配套设备,其核心元件是数控系统(比如西门子 SINUMERIK840Ds产品),它控制着机床所有的运动。机床的运动是山装在机床床身上 的伺服电机直接带动的,而电机是由装配在电气柜中的吸动器(比如西门]子S|NAM|C 产品)所控制。数控系统给毎一个驱动器下指令并协调驱动器之间的协同工作 除了数控系统和驱动器,数控柜里还集成了所有其它的操作机床工作的元件,比如传 感器、接触器以及电源等。 数控柜中集成了驱动器和可编程逻辑控制器,整个电气柜必须按照电磁兼容的标准去 设计,这栏才能保证设备的无故障运行。 PLC控制柜 对于所有的机器来说,它们都需要通过编程来实现相应的功能,所以需要一台计 算机來执行这些程序,对于工业应用來说,高可靠性至关重要。因此,可编程逻辑 控制器(PL得到了广泛应用比如西门子 SIMATIC产品)。PLC通过信号的输入输出来 检测和指挥机器设备,电气柜中的其他元件支持PLC采集和执行指令,从而实现相 应的功能。 电源分配柜 通常一台机器只冇一路电源进线,对于机器设备尤其是对于分布式控制的机器设 备,系统需要把电源分配到机器的不同用电位置。达到这个目的的电气柜就是电源 分配柜,为∫分配电流,电源分配柜通常配置有母线。高质量制造侏证了电源分配 柜安全可靠的应用, 驱动柜 如何控制电机的速度满足不同的应用需求,这一般都是由驱动系统(例如西门子的 MASTERDRIVE和 SIMODRIVE产品)实现的。多数情况下驱动系统装配在电气柜中, 电气柜要为驱动系统供电,给驱动系统提供冷却。在大多数工业领域,当人们设计 电气柜的时候都会非常关注驱动柜。 机器控制箱 电气装置的技术发展水平允许机器设备在全自动化和标准化的流程中去工作。但 是对于非标准的流程,比如说急停或测试以及编程,机器的用户就需要机器控 9目 制面板(MCP对机器进行手工操作。我们可以提供从简单的急停按钮盒到配备有触 摸屏、键盘以及手轮的控制箱。 a 高性能高品质 High Quality Excellent performance CNC Panel CNC panels are the powerful electrical counterpart of every machine tool. Key component is the Cnc unit (e. g. siemens SINUMERIK 840D sI), responsible to control all movements inside the machine. All movements of a modern machine tool will be caused by so-called servo motors assembled in the machine. They get controlled by their corresponding drive unit (e.g. siemens SINAMICS)within the cabinet. the cnc gives orders to all individual drive systems and coordinates them to each other Beside this, the Cnc panels integrate all other components which are necessary to operate the machine, like sensors, contactors, power supply and so on As the Cnc panel integrates drive as well as programmable units, the whole cabinet must be designed according to EMc standards in order to guarantee a faultless running PLC Panel For all machineries, which have to be programmed in order to achieve their functions, there must be a computer executing this program. High reliability is especially crucial in an industrial environment, therefore a so-called Programmable Logic Control(PlC) unit will be used(c.g. siemens SIMATIC). The Plc is checking and commanding the machine by having inputs and output signals All other components inside the cabinet support the PLC for this function of acquiring or executing the commands of the PLc Power Distribution Panel(PDP) In general, a machine has only one electrical power source. Especially for distributed machineries, the system has to split the power to the different parts of the machine. To manage the high currents, which the pdp has to distribute the Pdp are often equipped with copper busbars. a high manufacturing quality of the panels ensure a safe and reliable usage of these panels Drive Panel For a wide range of applications it is necessary to control the speed of the motors. This is done by drive systems(e. g MASTERDRIVE or SIMODRIVE). In most cases the drive systems will be put into the cabinets. The cabinet has the task to supply the drive systems, with electrical power as well as cooling. Especially for Drive panels there are reams of industry sector specific points to take care when designing the panel Machine Control panel State of the art electrical equipment allows the machine to run fully automatically for all standard processes. For non-standard processes, like emergencies or testing, and for re-programming the user of the machine needs the mcP to be able to control the machine manually. The MCP varies from simple emergency stop button boxes to control panels equipped with touchpanel, keyboard and machine specific hand wheels 行业概览 Industry Sectors Know-how 数控机床 产品:数控电柜 对于现代机床,无论是车床、铣床、磨床、φ床还是其他机床,其重要特点是高精度。不仅是机床的机械部件必须要高精度, 而且电气部件也同样需要高品质,特別是电磁兼容和电柜的冷却是高品质机床的有力保证。 ●SFAE对于电磁兼容的特点和布置有着丰富的经验,SFAE提供给机床厂的电柜遵循国际电磁兼容的标准。 ●特别是对于那些在恶劣环境下使用的机床,对于电器元件的加热或者制冷是机床质量的保障。SFAE对于电柜的设计,冷却 部件的选择有着丰富的经验,从而满足客户对于质量的要求。 纺织机械 ●产品:驱动柜 ·纺织机无论是织布还是纺纱、纺线,都需要电机及相应的电机驱动装置,位于控制柜內的驱动装置产生的热量对纺织机性 能有负面的影响,因控制柜需要有效的冷却,由于纺织机周围的空气通常被纺织物的粉尘污染,因此采用空调、排风扇这些 传统的冷却办法会导致频繁的故障甚至会造成机器损坏,SFAE可根据现代冷却概念,特别是近来广受客户赞誉的西门子“冷 却板”技术,为纺织机提供高效的、价格合理的冷却方案。 印刷机械 产品:驱动柜 现代印刷机性能先进,同时也对电气系统的质量有更高的要求,但这并不是元件品质的简单叠加,而是系统集成后得到更佳 的性能;一台典型的印刷机通常应用大量的电札及其驱动装置,以获得更高的性能,由于电内毎台驱动装置都会产生热量, 因此电柜冷却对于确保印刷机的性能及质量起到了至关重要的作用,由于印刷机周围的空气通常被纸张的粉尘污染,因此采 用空调、排风扇这些传统的冷却办法会导致频蘩的故障甚至会造成机器损坏,SFAE可根据现代冷却概念,为印刷机提供高效 的、价格合理的冷却方案。 高性能高品质 High Quality Excellent performance CNC Machine tool e Products: CNC Panels Modern machine tools are characterized for their high accuracy in turning, milling, grinding, punching and many more In order to achieve this target not only the mechanical parts of the machine have to be of highest quality but also the electrical components Especially topics like EMC and cabinet cooling are closely connected to achieve a high quality SFAE can provide years of experience in assessing cabinets considering their EMC characteristics and their layout SFAE provides cabinets to its machine tool customers which follow international standards regarding Emc. Especially for machine tools erected in regions with challenging climate conditions, the electrical components have to be cooled or heated accordingly to achieve a stable machinery quality SFAE has the experience of designing cabinets and choosing cooling units to achieve the customers request for high quality Textile machinery e Products: drive panels whether the machinery is weaving, yarning or winding, for all these processes the machines need motors and accordingly drive components inside the cabinet. For high performance textile machineries the drive components generate heat, which negatively affects the performance of the machine. Therefore the cabinets need to have an efficient cooling As the air around textiles machines is in general polluted by textile particles every conventional and cheap solution like air conditioners and fans would cause a frequent service or even a damage of the machine Sfae can provide modern cooling concepts, which are efficient, affordable and cause much less service. Especially Siemens'cold plate technology earned recently high appreciation from the customers Printing machinery e Products: Drive panels e State of the art printing machines have a high performance and a high level request to the quality of the electrical equipment. But the quality of electrical equipment is not only the sum of the quality of the components, but additionally putting all these puzzles together. Printing machines typically utilize a lot of motors and d to achieve its high performance. Due to the power loss of every drive in the cabinet, the cabinet cooling plays a crucia role to guarantee the machineries performance and quality as the air around printing machines is in general polluted by paper particles every conventional and cheap solution like air conditioners and fans would cause a frequent service or even a damage of the machine Sfae can provide modern cooling concepts, which are efficient, affordable and cause much less service 冒N 行业概览 Industry Sectors Know-how 风力发电 电柜类型:PLC柜,电源分配柜,变频柜 ●风电行业在全世界都处在快速发展阶段,许多制造企业都参予了对这个市场的竞争。长久以来,由于这个行业的技术门槛比 较高并且机器设备都要多年运转,所以只有那些能够提供可靠设备的企业才能够生存。正因为如此,所有的设备制造全业联 同他们的供应商都必须要考虑到这个行业的特殊性,尤其要考虑到工作环境的特殊要求。比如说,风电设备可能运转在荒漠 戈壁,也可能工作在海边,它的工作环境的温度变化范围非常大,同时不同地域的空气湿度差异很大。电气柜制造商是该行业 的核心供应商之一,他们需要和客户密切合作以迎接各种挑战,而西门子工厂自动化工程有限公司能够为风电客户提供经验、 提供支持帮助,悳意携于与客户在激烈的市场竞争当中共同成功。 港口机械/起重机 产品:PC柜,驱动柜,电源柜,操作台 ●与凤电行业一样,港机行业设备的稳定性也是由电气装置来保障。电气装置需要能够在海边恶劣的环境中稳定工作,并且能 够防止风、水和盐的腐蚀,这对器件的选型有着很高的要求。SFAE对满足恶劣环境下工作的器件选型有着丰富的经验:如柜 体的选择与密封、特殊喷漆、以及温度控制单元的添加等。 汽车制造 ●主要产品:PC控制柜,配电柜,生产机械控制柜 当前几乎所有的供应商一致认为汽车行业是以质量及过程为主要特点的,每一个供应商必须提供国东化的、高质量的产品 及服务。为了满足这些要求,西门子拥有覆盖仝球的盘柜生产网络以及对国际标准、规则(如CE、UL、CCC、GOST等)的深入了 解及经验。SFAE正将在汽车行业积累的多年经验应用在与国际客户的合作中,应客广要求可遵循不同的国乐标准。同时,作为 西门子全球网络的一员,SFAE提供全球范围的服务。 物流运输 产品:主配电柜,本地配电柜,PC柜,急停控制柜,电力控制柜 物流运输系统根据搾制要求和设备分布的不同,实现的功能也各不相同。市玚的发展要求整个系统具有髙吞吐量和低故障 率,5FAE控制电柜部能够为系统及设备的运行提供品质卓越、安仝可靠的控制柜,最大程度降低故障停机。针对调试运行 中的设计变更及运营期间的维护,SFAE强大的服务网络中心能为客户提供快速全面的服务。 航班号发陆 3U876成都 38761成都 四e
