安川变频器Varispeed L7B系列使用说明书(英文版).pdf

所需积分/C币:10 2019-09-25 20:29:59 9.65MB PDF
收藏 收藏
举报

安川变频器Varispeed L7B系列使用说明书(英文版)pdf,安川变频器Varispeed L7B系列为全世界的新型电梯和传统电梯提供完美的“舒适性”和卓越的“经济性”Varispeed L7B不但可以控制传统电梯中使用的异步电机(IM),还可控制电梯新趋势中的主流电机—同步电机(PM)。其卓越的“功能与性能”,实现了电梯的“舒适乘坐”,同时,其优异的“使用便利性”,使得调试和维护工作简单易行,具备变频器必备的所有条件。
Preface This manual is designed to ensure correct and suitable application of varispeed L7-Series Inverters. Read this manual before attempting to install, operate, maintain or inspect an Inverter and keep it in a safe, convenient location for future reference. Be sure you understand all precautions and safety information before attempt- ing application General Precautions The diagrams in this manual may be indicated without covers or safety shields to show details Be sure to restore covers or shields before operating the Units and run the Units according to the instructions described in this manual Any illustrations, photographs, or examples used in this manual are provided as examples only nd may not apply to all products to which this manual is applicable The products and specifications described in this manual or the content and presentation of the manual may be changed without notice to improve the product and/or the manual When ordering a new copy of the manual due to damage or loss, contact your Yaskawa represen tatives or the nearest Yaskawa sales office and provide the manual number shown on the front covel If nameplates become warn or damaged, order new ones from your Yaskawa representatives or the nearest Yaskawa sales office Safety Information The following conventions are used to indicate precautions in this manual. Failure to heed pre cautions provided in this manual can result in serious or possibly even fatal injury or damage to the products or to related equipment and systems Indicates precautions that, if not heeded, could possibly result in loss of life or serious injury WARNING Indicates precautions that, if not heeded, could result in relatively serious or minor injury. damage caution to the product, or faulty operation Failure lo heed a precaution classified as a caution can result in serious consequences depending on the situation Indicates important information that should be memorized IMPORTANT Safety Precautions Motor selection / WARNING Use only a Yaskawa permanent magnet motor in combination with this Inverter, specifically SSE4D-F021 Running any other permanent magnet motor with this Inverter may cause the Inverter to operate abnormally. Consult with Yaskawa before attempting to use a motor other than the model specified a Confirmations upon Delivery A CAUTION Never install an Inverter that is damaged or missing components Doing so can result in injury Installation /! CAUTION Always hold the case when carrying the Inverter Attach the Inverter to a metal or other noncombustible matera ossibly resulting in injury If the Inverter is held by the front cover, the main body of the Inverter may fall Fire can result if the inverter is attached to a combustible material Install a cooling fan or other cooling device when installing more than one Inverter in the same enclosure so that the temperature of the air entering the Inverters is below 45XC Overheating can result in fires or other accidents ■ Wiring △ WARNING Always turn OFF the input power supply before wiring terminals Otherwise. an electric shock or fire can occur Wiring must be performed by an authorized person qualified in electrical work electric shock or fil Be sure to ground the ground terminal (200 V Class: Ground to 100 Q2 or less, 400 V Class Ground to 10 q or less Always check the operation of any fast stop circuits after they are wired Othcrwisc, thcrc is the possibility of injury. (Wiring is thc responsibility of thc uscr. Never touch the output terminals directly with your hands or allow the output lines to come into con tact with the Inverter case. Never short the output circuits Otherwise. an electric shock or ground short can occur Do not use the Inverter for any load other than a three-phase Ac motor A permanent magnet motor is a type of permanent magnet motor with a rotor in which a magnet is integrated. Unlike an induction motor, the permanent magnet motor terminal generates high volt age when the motor is running, even when the Inverter power is shut off. Be sure to completely stop the motor before wiring, maintenance and inspection failure to do so may result in electric shock A WARNING Wire the Inverter so that the Run command switches off when a Stop command (or Fast stop com mand)is input to terminal BB or terminal BB1 If the run command is not removed then the motor will begin running as soon as the stop com mand (or Fast stop command)is cleared This can result in personal injury CAUTION Check to be sure that the voltage of the main ac power supply satisfies the rated voltage of the Inverter Injury or fire can occur if the voltage is not correct. Do not perform voltage withstand tests on the Inverter Otherwise, semiconductor elements and other devices can he damaged Connect braking resistors, Braking Resistor Units, and Braking Units as shown in the l/o wiring Otherwise, a firc can occur and the Invcrtcr, braking resistors, Braking Resistor Units, and Braking Units can bc damagcd Tighten all terminal screws to the specified tightening torque Otherwise, a firc may occur. Do not connect AC power to output terminals U, V, and W. Thc intcrior parts of the Invcrtcr will bc damaged if voltage is applicd to thc output terminals Do not connect phase-advancing capacitors or LC/RC noise filters to the output circuits The Inverter can be damaged or interior parts burnt if these devices are connected When a magnetic contactor is connected to the output circuits do not switch it on and OFF while Surge current will cause the overcurrent protection circuit inside the Inverter to operate This Inverter can drive an induction motor or a permanent magnet motor. Select a suitable control method(parameter A1-02 )for the motor you drive Failure lo do so will cause darnage to the molor Setting User Parameters / WARNING Do not change the factory setting(0)in b1-03(Run Command source selection) Doing so can causc thc elevator to drop Do not change the factory setting(1)in L8-05 (Input open-phase protection selection) You can change it to O, but only after confirming that there are no factors that cause input open phase Doing so may damage the Inverter main circuits /! CAUTION Disconnect the load (machine, device) from the motor before performing rotational autotuning or pole tuning The motor may turn, possibly resulting in injury or damage to equipment. Also, motor parameters cannot be correctly set with thc motor attached to a load Stay clear of the motor until rotational autotuning or pole tuning has been successfully completed The motor could stop and then start again unexpectedly and this could rcsult in injury Always confirm the following before rotational autotuning or pole tuning The lock key has been removed from the motor shaft There are neither people nor objects around the motor shaft. The motor is at a complete stop Failure to do so may result in injury Be careful when handling the shaft and coupling Failure to do so may result in injury. Be careful not to injure yourself with the key groove when turning the motor shaft by hand Failure to do so may result in injury When operating a permanent magnet motor for the first time, or after exchanging a permanent magnet motor or an Inverter, set a correct motor parameter to the inverter before the operation and be sure to check the motor speed detection Shortage of torque may be the cause when the motor is pulled in the load direction or when the motor does not run as directed such as reverses. doesn't work. or over-accelerates Refer to Chapter 4 Trial Operation for details Do not change the parameter settings unnecessarily Doing so may impede motor operation When running a permanent magnet motor, be sure to set the following parameters Motor related parameters(E1-日日,E5-口) Parameters for Pg open- circuit detection function(F1-oo Parameters for excessive speed deviation detection function(F1-o0) Parameters for over-acceleration detection function (S3-ao) Failure lo du ill If running a permanent magnet motor with any option cards other than the PG-F2 card, and not using the braking sequence recommended by this Ir set the following braking sequer After inputting the operational order, or closing the pole detection complete signal, release the braking A basket will be pulled by a counter weighl. Be careful uf this, as it can cause injury If running a permanent magnet motor with any option cards other than the PG-F2 card, note that the Inverter has not been adapted for use with batteries. If so, do not select the battery as the Shortage of torque may be the cause when the motor is pulled in the load direction or when the motor does not run a directed. such as reverses doesn t work or over-accelerales ■ Trial operation △ WARNING Check to be sure that the front cover is attached before turning on the power supply An electric shock may occur Provide a separate fast stop switch; the Digital Operator StoP Key is valid only when its function is et Inju Reset alarms only after confirming that the RUn signal is OFF Injur CAUTION Do not touch the radiation fins(heatsink), braking resistor, or Braking Resistor Unit. These can become very hot Otherwise, a burn injury may occur Be sure that the motor and machine is within the applicable ranges before starting operation Otherwi may occur. Provide a separate holding brake if necessary Always construct the external sequence to confirm that the holding brake is activated in the event of an emergency, a power failure, or an abnormality in the Inverter Failure to observe this caution can result in injury If using an Inverter with a elevator, take safety measures on the elevator to prevent the elevator from dropping Failure to observe this caution can result in injury Do not check signals while the Inverter is running Otherwise, the equipment may be damaged Be careful when changing Inverter settings. The Inverter is factory set to suitable settings Otherwise, the equipment may be damaged. Maintenance and Inspection WARNING Do not touch the Inverter terminals. Some of the terminals carry high voltages and are extremely dangerous Doing su can result in electric shock attaching the cover, always turn OFF power to the Inverter through the mcCB nverter When Always have the protective cover in place when power is being supplied to the Doing so can result in electric shock After turning ofF the main circuit power supply, wait for the time indicated on the front cover, and make sure the ChaRGe indicator light has gone out, and then perform maintenance and inspec- The capacitor will remain charged and is dangerous Maintenance, inspection, and replacement of parts must be performed only by authorized person nel Remove all metal objects, such as watches and rings, before starting work. Always use grounded tools failure to heed these warning can result in electric shoc Be sure to completely stop the permanent magnet motor before maintenance and inspection Failure lo do so may result in elecTric shock A CAUTION A CMOS IC is used in the control board. Handle the control board and CMos iC carefully IC can be destroyed by static electricity Do not change the wiring, or remove connectors or the Digital Operator, during operation Doing so can result in personal injury ■ Other △ WARNING Do not attempt to modity or alter the Inverter Doing so can result in electrical shock or injury CAUTION Do not subject the Inverter to halogen gases, such as fluorine, chlorine, bromine, and iodine, at any time even during transportation or installation Otherwise, the Inverter can he damaged or interior parts burnt ⅦT Warning Labels on the Inverter Be sure to read and follow all warning labels on the Inverter before installation Warnings here listed [ CIMR-L7B23P7(example CIMR-L7B2022(example Text on Warning labels △ WARNING A Risk of electric shock Read manual before installing Wait 5 minutes for capacitor discharge after disconnecting power supply After opening the manual switch between the drive and motor, please wait 5 minutes before inspecting, performing maintenance or wiring the drive AAVERTISSEMENT A Lire le manuel avant I' installation Attendre 5 minutes apres la coupure de I' allmentation. P( ttre la decharge des condensateurs Apres avoir deconnecte la protection entra le drive et le moteur veuillez patienter 5 minutes avant d inspecter, d effectuer une operation de montage ou de cablage du variateur 危唉 A 水·感電①扮子礼小刂志寸 据元付计·運輮叨前[忒必寸取极說明甚 誌孙下凼L 通電中及U電源遮断後5分以內(夕玉才儿 力八一在外本Q下志U ·保守·点樸,配線左行場合|,出力側手 動開閉器左遮断後,5分待τ实施Lτ下L
