安川变频器Varispeed G7B系列使用说明书(英文版)pdf,安川变频器Varispeed G7B系列:顺应用户具体需求、不断创新的Varispeed系列安川变频器。在通用变频器中Varispeed G7首次采用“3电平控制方式”,用“3电平控制方式”解决了冲击波问题,可以放心地驱动现用电机。真正的电流矢量控制所拥有的高性能、多功能,可以使各式各样的机械设备在高效率高精度状态下运行。
Preface This manual is designed to ensure correct and suitable application of Varispeed G7-Series Inverters. Read this manual before attempting to install, operate, main tain, or inspect an Inverter and keep it in a safe, conve- nient location for future reference be sure you understand all precautions and safety information before attempting application General Precautions The diagrams in this manual may be indicated without covers or safety shields to show details Be sure to restore covers or shields before operating the Units and run the Units according to the instructions described in this manual Any illustrations, photographs, or examples used in this manual are provided as examples only and may not apply to all products to which this manual is applicable The products and specifications described in this manual or the content and presentation of the manual may be changed without notice to improve the product and or the manual When ordering a new copy of the manual due to damage or loss, contact your Yaskawa represen- tatives or the nearest Yaskawa sales office and provide the manual number shown on the front covel If nameplates become warn or damaged, order new ones from your Yaskawa representatives or the nearest Yaskawa salcs officc Safety Information The following conventions are used to indicate precautions in this manual. Failure to heed pre- cautions provided in this manual can result in serious or possibly even fatal injury or damage to the products or to related equipment and systems Indicates precautions that, if not heeded, could possibly result in loss of life or serious injury WARNING Indicates precautions that, if not heeded, could result in relatively serious or minor injury. damage /! CAUTION to the product, or faulty operation Failure to heed a precaution classified as a caution can result in serious consequences depending Indicates tant information that should be memorized IMPORTANT Safety precautions Confirmations upon Delivery 个cAUT|oN Never install an Inverter that is damaged or missing components ng so alt in injur ■ Installation CAUTION Always hold the case when carrying the Inverter If the Inverter is held by the front cover, the main body of the Inverter may fall, possibly resulting in injury Attach the inverter to a metal or other noncombustible mate Fire can result if the inverter is attached to a combustible material Install a cooling fan or other cooling device when installing more than one Inverter in the same enclosure so that the temperature of the air entering the Inverters is below 45C Overheating can result in fires or other accidents ■ Wiring A WARNING Always turn OF F the input power supply before wiring terminals Otherwise. an electric shock or fire can occur Wiring must be performed by an authorized person qualified in electrical work Otherwise, an electric shock or fire can occur Be sure to ground the ground terminal.(200 V Class: Ground to 100 Q2 or less, 400 V Class Ground to 10 o or less Otherwise. an electric shock or fire can occur Always check the operation of any emergency stop circuits after they are wired Otherwise, there is the possibility of injury. (Wiring is the responsibility of the user. Never touch the output terminals directly with your hands or allow the output lines to come into con tact with the Inverter case. Never short the output circuits Otherwise. an clcctric shock or ground short can occur If the power supply is turned on during the FWD(or REV) Run Command is given, the motor will start automaticall Turn the power supply oN after verifying that the run signal is OFF Failure to observe this warning may rcsult in injury When the 3-wire sequence is set, do not make the wiring for the control circuit unless the multi function input terminal constant is set Failure to observe this warning may result in injury ∧ CAUTION Check to be sure that the voltage of the main ac power supply satisfies the rated voltage of the Injury or fire can occur if the voltage is not correct Do not perform voltage withstand tests on the Inverter Connect braking resistors, Braking Resistor Units, and Braking Units as shown in the l/O wiring examples Otherwise, a firc can occur and the Invcrtcr, braking resistors, Braking Resistor Units, and Braking Units can bc damagcd CAUTION ighten all terminal screws to the specified tightening torque Otherwise, a fire may occur Do not connect Ac power to output terminals U, V, and W. The interior parts of the Inverter will be damaged if voltage is applied to the output terminals Do not connect phase-advancing capacitors or LC/RC noise filters to the output circuits The Inverter can be damaged or interior parts burnt if these devices are connected Do not connect magnetic contactors to the output circuits If a load is connected while the Inverter is operating, surge current will cause the overcurrent protection circuit inside the o operat Setting User Constants A CAUTION Disconnect the load(machine, device) from the motor before performing rotational autotuning The motor may turn, possibly resulting in injury or damage to equipment. Also, motor constants cannot be correctly set with the motor attached to a load Stay clear of the motor during rotational autotuning The motor repeats running and stopping until autotuning has been completed, possibly resulting in injury In stationary autotuning 1, when the motor is first operated in the drive mode after tuning, the remaining motor constants E2-02 (Motor rated slip)and E2-03(Motor no-load current) are set auto matically. To perform an operation immediately after stationary autotuning 1, use the following pro- cedure under the recommended conditions (1) Check the values of E2-02 and E2-03 in verify mode or advanced programming mode (2)Run the motor once in drive mode under the following conditions The Inverter and the motor are connected The motor shaft is not locked with a mechanical brake or other stopping mechanism(or function) A motor-load ratio of 30% or less is maintained A speed of 30% or more of the base frequency set at E1-06 ( default= highest frequency) is maintained at a constant speed for one second or more (3)After stopping the motor, check the values of E2-02 and E2-03 again in verify mode or advanced program- ming mode. If the values of E2-02 and E2-03 differ from the ones before the first operation was carried out, the settings have been successfully completed. Next, check if the values are suitable or not If the values of E2-02 and E2-03 differed greatly from the reference data of the motor in the test report or the instruction manual(TOE-S616-60.1), hunting, motor vibrations, insufficient motor torque, or an overcurrent may occur because the motor is operated although the aforementioned conditions have not been fulfilled after stationary autotuning 1. For eleva- In stationary autotuning I again and run the motor using the aforementioned procedure under the recommended conditions or perform stationary autotuning 2 lational autoly Usually the standard setting for E2-02 is I Hz to 3 HZ, and that for E2-03 is 30% to 65%o of the rated current for a general purpose motor. Generally, the larger the motor capacity is, the smaller the rated slip and the ratio of the no-load current to the rated current become. Use the data given in Factory Settings that Change with the Inverter Capacity 102-04)of Chap ter 5 User Constants as a reference Trial operation A WARNING Check to be sure that the front cover is attached before turning on the power supply An electric shock may occur Do not come close to the machine when the fault reset function is used if the alarmed is cleared the machine may start moving suddenly Al the machine so that human safety is ensured even when it is restarted Injury may occur Provide a separate emergency stop switch; the Digital Operator STOP Key is valid only when its function is set Injury may occur A WARNING Reset alarms only after confirming that the run signal is OFF. Injury may occur A CAUTION Dont touch the radiation fins(heatsink), braking resistor, or Braking Resistor Unit. These can become very hot Otherwise, a hurn injury may occur. Be sure that the motor and machine is within the applicable ranges before starting operation Otherwise. an injury may occur. Provide a separate holding brake if necessary Always construct the external sequence to confirm that the holding brake is activated in the event of an emergency, a power failure, or an abnormality in the inverter Failure to observe this caution can result in injury If using an Inverter with an elevator, take safety measures on the elevator to prevent the elevator Failure to observe this caution can result in injury. Don't check signals while the Inverter is running Otherwise, the equipment may he damaged Be careful when changing Inverter settings. The Inverter is factory set to suitable settings. For the Inverters in the 400 v class of 55 kw or more, however, select the correct power supply voltage jumper according to the input voltage Otherwise, the equipment may be damaged Maintenance and Inspection A WARNING Do not touch the Inverter terminals. Some of the terminals carry high voltages and are extremely dangerous Doing so can result in electric shock. Always have the protective cover in place when power is being supplied to the Inverter. When attaching the cover, always turn OFF power to the Inverter through the mcCB Doing so can result in electric shock After turning OFF the main circuit power supply, wait until the CHARGe indicator light goes out before performing maintenance or inspections The capacitor will reMain charged and is dangerous Maintenance, inspection, and replacement of parts must be performed only by authorized person Remove all mctal objects, such as watches and rings, bcforc starting work. Always usc grounded tools Failure to heed these warning can result in electric shock Provide a separate holding brake if necessary Always make any adjustments other than those involving the operation of the Inverter with the holding brake released Failure to observe this caution may result in injury If using an Inverter with an elevator, take safety measures on the elevator to prevent the elevator from dropping Failure to observe this caution can result in injury CAUTION A CMOS IC is used in the control board Handle the control board and CMOS IC carefully. The CMOs IC can be destroyed by static electricity if touched directly Do not change the wiring, or remove connectors or the Digital Operator, during operation Doing so can result in personal injury A WARNING Do not attempt to modify or alter the Inverter. Doing so can rcsult in clectrical shock or injury. A CAUTION Do not subject the Inverter to halogen gases, such as fluorine, chlorine, bromine, and iodine, at any time even during transportation or installation Otherwise, the Inverter can be damaged or interior parts burnt i Warning Information and Position There is warning information on the Inverter in the position shown in the following illustration Always heed the warnings Warning information Warning sitio llustration shows the cIMR-G7B20P4 Illustration shows the cimr-G7B2018 Warning Information A WARNING Risk of electric shock Read manual before installing Wait 5 minutes for capacitor discharge after disconnecting power supply AVERTISSEMENT A Riso que de decharge electrique Lire le manuel avant l' installation Attendre 5 minutes apres la coupure de I allmentation. Pour permettre la decharge des condensateurs △危险 A 有受伤、触电危险 ·安装、运行前务必先阅读使用说明书。 通电时及电源切断后5分钟以内, 不要打开端子排外壳 Warranty Information Free Warranty Period and Scope Warranty Period This product is warranted for twelve months after being delivered to Yaskawa's customer or if applicable eighteen months from the date of shipment from Yaskawa's factory whichever comes first Scope of Warranty spections Periodic inspections must be conducted by the customer. However, upon request, Yaskawa or one of Yaskawa's Service Centers can inspect the product for a fee. In this case, if after confer ring with the customer, a Yaskawa product is found to be defective due to Yaskawa workman- ship or materials and the defect occurs during the warranty period, then this fee will be waived and the problem remedied free of charge Repairs If a Yaskawa product is found to be defective due to yaskawa workmanship or materials and the defect occurs during the warranty period, Yaskawa will provide a replacement, repair the defec- tive product, and provide shipping to and from the site free of charge However, if the Yaskawa Authorized Service Center determines that the problem with a Yaskawa product is not due to defects in Yaskawa's workmanship or materials, then the cus- tomer will be responsible for the cost of any necessary repairs. Some problems that are outside the scope of this warranty are Problems due to improper maintenance or handling, carelessness, or other reasons where the customer is determined to be sible Problems due to additions or modifications made to a Yaskawa product without Yaskawa's understanding Problems due to the use of a Yaskawa product under conditions that do not meet the recom mended specifications Problems caused by natural disaster or fire Or other problems not due to defects in Yaskawa workmanship or materials Warranty service is only applicable within Japan However, after-sales service is available for customers outside of Japan for a reasonable fee Contact your local Yaskawa representative for more information ■ Exceptions Any inconvenience to the customer or damage to non- Yaskawa products due to Yaskawa's defective products whether within or outside the warranty period are NOT covered by this war- randy Restrictions The Varispeed G7 was not designed or manufactured for use in devices or systems that may directly affect or threaten human lives or health Customers who intend to use the product described in this manual for devices or systems relating to transportation, health care, space aviation, atomic or electric power, or underwater use must contact their Yaskawa representatives or the nearest Yaskawa sales office before ane This product has been manufactured under strict quality-control guidelines. However, if this product is to be installed in any location where failure of this product could involve or result in a life-and-death situation or loss of human life or in a facility where failure may cause a serious accident or physical injury, safety devices must be installed to minimize the likelihood of any accident
