ARON AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. Revision History Version Change Summary Date Author 0.10 Created 28-July-2012 Benefit 0.20 Update rOom 15-SEP-2012 Raindrop AR8159 Low Noise Amplifier for GPS/GNSS age 3 of 10 CONFIDENTIAL Preliminary Datasheet Version 0.20 15-Nov-2012 Copyright 2012, Airoha Technology Corp AROHN AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. INDEX Revision History 1 Feature 5 2 Description…… 3 Pin Assignment,,,,……,……,…,…,……6 3.1 PIN NAME DESCRIPTION 申中和鲁申p中中申非中中中和申中·中·中中·中中申非中申电中·中中非1 4 Electrical characteristics ■■aa日 4.1 ABSOLUTE MAXIMUM RATINGS. ...........................................................................................7 4.2 DC ELECTRICAL SPECIFICATIONS ···········:···········:·············:······· 7 4.3 AC ELECTRICAL SPECIFICATIONS 和中和中, 5 Package Dimension 6 Schematic AR8159 Low Noise Amplifier for GPS/GNSS age 4 of 10 CONFIDENTIAL Preliminary Datasheet Version 0.20 15-Nov-2012 Copyright 2012, Airoha Technology Corp ARON AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. 1 Feature Support full GNSs Ll band: 1559MHZN1610MHZ Low noise figure: 0. 8 dB High gain: 19 dB High Input Pl-dB:-12 dBm High In-band IIIP3:-5 dBm Support 1.6 N 3. 6 v supply voltage ow supply current: 4.1mA ow disable current <1uA Small package: 6-pin uDFN 1 0mm x 1.5mm x075mm 2 Description The aR8159 is a high gain, low noise amplifier(LNA) for GPS, GLONASS Galileo, and Compass applications. It operates from 1. 6v to 3. 6V and achieves 19 db gain and 0. 8 dB noise figure while giving a high linearity The current consumption of AR8159 in enable mode and disable mode are 4.1ma and <luA respectively. The AR8159 is in a very small, lead-free, roHs-compliant, 1.5mm x 1. 0mm x 0.75mm 6-pin uDEN package. It requires low bill of materials, including one external matching inductor, one bypass capacitor and one dc blocking capacitor. The ar8159 is the best solution to improve the GPs receiver performance obviously and easily AR8159 Low Noise Amplifier for GPS/GNSS age 5 of 10 CONFIDENTIAL Preliminary Datasheet Version 0.20 15-Nov-2012 Copyright 2012, Airoha Technology Corp AIROHN AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. 3 Pin Assignment GND AR8159 RFOUT GND EN REIN 4 VCC 3. 1 Pin Name Description PIN SIGANL TYPE DESCRIPTION GND GND Ground GND GND Ground 3 RFIN Input, Analog RF input 4 VCO VCC Supply Supply Voltage EN Input, Digital Enable control 6 RFOUT Output, Analog RF output AR8159 Low Noise Amplifier for GPS/GNSS age 6 of 10 CONFIDENTIAL Preliminary Datasheet Version 0.20 15-Nov-2012 Copyright C 2012, Airoha Technology Corp AIROHN AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. 4 Electrical characteristics 4.1 Absolute Maximum Ratings AR8159 could be damaged by any stress in excess of the absolute maximum ratings listed below ITEM MIN MAX Power supply voltage(vcc) 0.3V 4.2V Pin voltage -0.3V VCC +0.3V Operating temperature 40C +85心C Storage temperature -65YC +160C LNA input level +10 dBm 4.2 DC Electrical Specifications Recommended operating ambient temperature range TA =-40 to 85YC tem Symbol Test Condition Min Typ. Max Unit VCC Supply voltage VCC 1.6 3.6 VCC Supply Current EN=1 4.1 5.6 mA Power down current Ivcc EN=0 Digital Input Voltage- High Level igital Input Voltage- Low Level 0.4 Digital Input Current -High Level VIN=VCC=3.6V 1 Digital Input Current-Low Level VIN=OV VCC=3.6V 1 RFIN DC Voltage EN=1 0.5 V AR8159 Low Noise Amplifier for GPS/GNSS age 7 of CONFIDENTIAL Preliminary datasheet Version 0.20 15-NOV-2012 Copyright 2012, Airoha Technology Corp AIROHN AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. 4.3 AC Electrical specifications Typical values are tested under Freq=1575.42MHZ, VCC=2.8V, Ta=25C unless otherwise specified PARAMETER CONDITION M工N TYP MAX UNIT Gain 19 dB Noise Figure 0.8 dB P1-d 12 dBm f1=MHz, f2=MHz In-band iiP3 P1=P2=dBm Input Return Loss 10 11 dB Output Return Loss dB Reverse isolation B Turn-ON Time With 10% off the final gain TBD Us Turn-OFF Time With 10% off the final gain TBD Us AR8159 Low Noise Amplifier for GPS/GNSS age 8 of 10 CONFIDENTIAL Preliminary datasheet Version 0.20 15-NOV-2012 Copyright 2012, Airoha Technology Corp AIROHN AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. 5 Package Dimension MISWBL 5X 1-6L (PD. 50T0 75) PACKAGE OUTLINE DINENSICNS TOP VIE BOTTOMAVIEY SIDE V Symbol Dimensions In Millimeters Dimensions In Inches Min Max Min Max 0.700 0.800 0.028 0031 0000 0050 0.000 0.002 A3 0.110REF 0.005REF D 1450 1550 0.057 0061 0.950 1.050 0.037 0.041 D1 b 0.150 0250 0.006 0010 0.500TYP 0.020TYP 0.000 0.008 0.000 0000 0.350 0450 0.014 0018 0.300 0400 0.012 0016 AR8159 Low Noise Amplifier for GPS/GNSS age 9 of 10 CONFIDENTIAL Preliminary datasheet Version 0.20 15-NOV-2012 Copyright 2012, Airoha Technology Corp AIROHN AR8159 Low Noise Amplifier for GPS/GNSS Airoha Technology Corp. 6 Schematic RFOUT GND AR8159 RF IN VCC Bill-of-materials Symbol value Unit Manufacturer Comment C1 56 dc block C2 100 nF arIous RF byp ass L1 10 nH Murata LQW15A Input matching AR8159 Low Noise Amplifier for GPS/GNSs Page 10 of 10 CONFIDENTIAL Preliminary datasheet Version 0.20 15-NOV-2012 Copyright 2012, Airoha Technology Corp

...展开详情
试读 10P AR8159_DataSheet.pdf
wcq999

关注 私信 TA的资源

上传资源赚积分,得勋章
    最新推荐
    AR8159_DataSheet.pdf 35积分/C币 立即下载
    1/10
    AR8159_DataSheet.pdf第1页
