JEDEC
STANDARD
Solder Ball Shear
JESD22-B117B
(Revision of JESD22-B117A, October 2006)
MAY 2014 (Reaffirmed September 2020)
JEDEC SOLID STATE TECHNOLOGY ASSOCIATION
poorest

NOTICE
JEDEC standards and publications contain material that has been prepared, reviewed, and
approved through the JEDEC Board of Directors level and subsequently reviewed and approved
by the JEDEC legal counsel.
JEDEC standards and publications are designed to serve the public interest through eliminating
misunderstandings between manufacturers and purchasers, facilitating interchangeability and
improvement of products, and assisting the purchaser in selecting and obtaining with minimum
delay the proper product for use by those other than JEDEC members, whether the standard is to
be used either domestically or internationally.
JEDEC standards and publications are adopted without regard to whether or not their adoption
may involve patents or articles, materials, or processes. By such action JEDEC does not assume
any liability to any patent owner, nor does it assume any obligation whatever to parties adopting
the JEDEC standards or publications.
The information included in JEDEC standards and publications represents a sound approach to
product specification and application, principally from the solid state device manufacturer
viewpoint. Within the JEDEC organization there are procedures whereby a JEDEC standard or
publication may be further processed and ultimately become an ANSI standard.
No claims to be in conformance with this standard may be made unless all requirements stated in
the standard are met.
Inquiries, comments, and suggestions relative to the content of this JEDEC standard or
publication should be addressed to JEDEC at the address below, or refer to www.jedec.org under
Standards and Documents for alternative contact information.
Published by
©JEDEC Solid State Technology Association 2020
3103 North 10th Street
Suite 240 South
Arlington, VA 22201-2107
This document may be downloaded free of charge; however JEDEC retains the
copyright on this material. By downloading this file the individual agrees not to
charge for or resell the resulting material.
PRICE: Contact JEDEC
Printed in the U.S.A.
All rights reserved
poorest

JEDEC Standard No. 22B117B
Page 1
Test Method B117B
(Revision of B117A)
TEST METHOD B117B: SOLDER BALL SHEAR
(From JEDEC Board Ballot, JCB-14-10, formulated under the cognizance of the JC-14.1 Subcommittee
on Reliability Test Methods for Packaged Devices.)
1
Scope
This document describes a test m ethod only; acceptance criteria and qualification requirements
are not defined. This test method applies to solder ball shear force/energy testing prior to end-use
attachment. Solder balls are sheared individually; force, fracture energy and failure m ode data
are collected and analyzed. Both low- and high-speed testing are covered by this document.
Depending on test sample configuration, applicati on, and purpose of the test (characterization,
qualification, production, etc.), other solder joint integrity as sessment methods such as JEDEC
Solder Ball Pull Test Method JESD 22-B115, may be more appropriate. Ge nerally, solder ball
shear is most approp riate for d evices that experience shear loading during either the
manufacturing/shipment process, or end use.
This test method is used to assess the ability of solder balls to withstand mechanical shear forces
that may be applied during device m anufacturing, handling, test, shipm ent, and end-use
conditions. Solder ball shear is a destructive test. Th is test m ethod provides qualitative results
and is suitable for process and material characterization.
2 Terms and definitions
base material: The substrate of the device where the solder balls are attached.
clamping fixture: A fixture that holds the device rigidly during solder ball shear testing
(see Figure 2).
elapsed time after reflow: The elapsed time between solder ball shear and last reflow of solder
ball.
failure mode: The type or location of failure observed after the solder ball is sheared.
fracture energy: The total energy required to fracture the solder ball.
NOTE Typically fracture energy is calculated by integrating the force versus displacement during the
solder-ball-shear process.
high-speed shear: Shear occurring at a speed that produces a low-energy interfacial fracture of
the solder ball; that speed is typically greater than 50 mm/s.
poorest

JEDEC Standard No. 22B117B
Page 2
Test Method B117B
(Revision of B117A)
2 Terms and definitions (cont’d)
low-speed shear: Shear occurring at a speed that is typically 0.1 mm – 0.8 mm/s
(100 μm/s – 800 μm/s).
null-drift calibration: The procedure whereby the load transducer output is periodically reset to
a value of zero, separately from a transducer calibration.
post-stress test: Solder ball shear evaluation performed after reliability stress testing such as
temperature cycling or high-temperature storage.
shear force: The shear load applied to a solder ball in a direction parallel to the device planar
surface.
shear speed: The nominal rate at which the shear tool moves in a direction parallel to the device
planar surface as it shears the solder ball.
shear tool: A rigid tool that presses directly against the solder ball during shearing
(see Figure 1).
NOTE The shear tool is integrated with a sensing element so that shear force can be measured.
shear tool standoff: The distance between the device planar surface and the shear tool tip
(see Figure 1).
test apparatus: An instrument used to shear the solder ball from the test sample and measure the
load applied to the solder ball.
NOTE High-speed shear apparatus also measures the displacement.
3 Apparatus
The test apparatus can be specifically designed for solder ball shear testing, or it may be possible
to utilize a general mechanical load-deflection test instrument. The apparatus must be capable of
shearing solder balls at a known c onstant rate of displacement (t est speed) and m ust be capable
of recording generated shear loads as a function of distan ce and time through the use of a
calibrated load cell or sensing elem ent. The shear tool alignment to the solder ball a nd standoff
from the base m aterial are shown in Figure 1. Separate equipm ent may be required to perform
both low- and high-speed shear testing. Depending upon specific te st sample construction and
application, critical param eters associated with the tes t apparatus may vary from one test to
another; Section 4 describes the various test parameters and the recommended reporting of these
variables.
poorest
