文章编号:1000-2278(200402-0102-06
全自动液压压砖机CAD CAE 信息集成系统数据库的研究与开发
肖任贤 吴南星 潘海鹏 杨 帆
(景德镇陶瓷学院机械电子工程学院,333001
摘 要
对全自动液压压砖机CAD CAE
信息集成系统中的工程数据库的设计和实施进行了研究,分析了系统对数据信息的需求,提
出了该系统数据库的E-R 数据模型以及表的定义和结构关系,实现了压砖机CAD CAE
信息集成系统。关键词:全自动液压压砖机,数据库,信息需求,信息集成中图法分类号:TQ17
4.6 文献标识码:A
RESEARCH AND DEVELOPMENT ON THE DATABASE IN THE CAD CAE
INFORMATION INTEGRATED SYSTEM OF THE
PORCELAIN AUTOMATIC HYDRAULIC PRESS
Xiao Renxian Wu Nanxing Pan Haipeng Yang Fan
(Jingdezhen Cera mic Institute,333001
Abstract
This paper studied the design of database in CAD C AE information integrated system of
the porcelain automatic hydraulic press,analyzed the damand for the data infor mation of the
system,put forward the E-R data model and the definition of tables as well as their struc ture
relations,and realized C AD CAE information integrated syste m of the porcelain automatic
hydraulic press.
Keywords automatic hydraulic press,database,data demand,information inte grated
