Chapter 2
Discrete-Time Signals and Systems
P2.1 Generate the following sequences using the basic Matlab signal functions and the basic Matlab signal
operations discussed in this chapter. Plot signal samples using the stem function.
1. x
1
(n) = 3δ(n + 2) + 2δ(n) − δ(n − 3) + 5δ(n − 7), −5 ≤ n ≤ 15
% P0201a: x1(n) = 3*delta(n + 2) + 2*delta(n) - delta(n - 3) +
% 5*delta(n - 7), -5 <= n <= 15.
clc; close all;
x1 = 3*impseq(-2,-5,15) + 2*impseq(0,-5,15) - impseq(3,-5,15) ...
+ 5*impseq(7,-5,15);
Hf_1 = figure; set(Hf_1,’NumberTitle’,’off’,’Name’,’P0201a’); n1 = [-5:15];
Hs = stem(n1,x1,’filled’); set(Hs,’markersize’,2);
axis([min(n1)-1,max(n1)+1,min(x1)-1,max(x1)+1]);
xlabel(’n’,’FontSize’,LFS); ylabel(’x_1(n)’,’FontSize’,LFS);
title(’Sequence x_1(n)’,’FontSize’,TFS);
set(gca,’XTickMode’,’manual’,’XTick’,n1,’FontSize’,8);
print -deps2 ../EPSFILES/P0201a;
The plots of x
1
(n) is shown in Figure 2.1.
3
