CHIMEI INNOLUX DISPLAY CORPORATION
LCD MODULE
SPECIFICATION
Customer:
Model Name: AT043TN25 V.2
SPEC NO.: A043-25-TT-21
Date: 2010/09/15
Version: 01
□
□□
□ Preliminary Specification
■
■■
■ Final Specification
For Customer’s Acceptance
Approved by Comment
Approved by Reviewed by Prepared by
Hans Chen
2010/11/09
James Yu
Charlie Chou
2010/11/05
David Lee
2010/11/04
CHIMEI INNOLUX
InnoLux copyright 2004
All rights reserved,
Copying forbidden.
Record of Revision
Version Revise Date Page Content
Pre-spec .01 2010/05/14 Initial Release.
Final-Spec.01 2010/09/15
1 Add Power and Weight
CHIMEI INNOLUX
Contents
1. General Specifications ……………………………………………………………………………...1
2. Pin Assignment ……………………………………………………………………………...…2
2.1. TFT LCD Panel Driving Section .................................................................................. ….2
3. Operation Specifications …………………………………………………………………………4
3.1. Absolute Maximum Ratings..............................................................................................4
3.2. Typical operation conditions .............................................................................................5
3.3 Backlight Driving Conditions .............................................................................................5
3.4. Power Sequence ..............................................................................................................6
3.5. Timing Characteristics ......................................................................................................7
3.5.1. Timing Conditions ......................................................................................................... 7
3.5.2.Timing Diagram .............................................................................................................8
4. Optical Specifications ……………………………………………………………………… ………9
5. Reliability Test Items ……………………………………………………………………………….13
6. General Precautions …………………………………………………………………………….…14
7.1. Safety ............................................................................................................................14
7.2. Handling ........................................................................................................................14
7.3. Static Electricity..............................................................................................................14
7.4. Storage ..........................................................................................................................14
7.5. Cleaning ........................................................................................................................14
7. Mechanical Drawing ……………………………………………………………………………….15
9. Package Drawing ……………………………………………………………………………….16
9.1. Packaging Material Table...............................................................................................16
9.2. Packaging Quantity........................................................................................................16
9.3. Packaging Drawing........................................................................................................17
CHIMEI INNOLUX SPEC NO.: A043-25-TT-21
Date : 2010/09/15 Page : 1/22
1. General Specifications
No. Item Specification Remark
1 LCD size 4.3 inch(Diagonal)
2 Driver element a-Si TFT active matrix
3 Resolution 480 × 3 (RGB) × 272
4 Display mode Normally White, Transmissive
5 Dot pitch 0.066(W) × 0.198(H) mm
6 Active area 95.04(W) × 53.856(H) mm
7 Module size 105.5(W) × 67.2(H) ×2.9(D) mm Note 1
8 Surface treatment Anti-Glare
9 Color arrangement RGB-stripe
10 Interface Digital
11 Backlight Power consumption
0.558 W(Typ.)
12 Panel Power consumption 0.056 W (Typ.)
13 Weight 45g (Typ.)
Note 1: Refer to Mechanical Drawing.
CHIMEI INNOLUX SPEC NO.: A043-25-TT-21
Date : 2010/09/15 Page : 2/22
2. Pin Assignment
2.1. TFT LCD Panel Driving Section
FPC Connector is used for the module electronics interface. The recommended model
is “FH19SC-40S-0.5SH” manufactured by HIROSE.
Pin No.
Symbol I/O Function Remark
1 V
LED-
P Power for LED backlight cathode
2 V
LED+
P Power for LED backlight anode
3 GND P Power ground
4 V
DD
P Power voltage
5 R0 I Red data (LSB)
6 R1 I Red data
7 R2 I Red data
8 R3 I Red data
9 R4 I Red data
10 R5 I Red data
11 R6 I Red data
12 R7 I Red data (MSB)
13 G0 I Green data (LSB)
14 G1 I Green data
15 G2 I Green data
16 G3 I Green data
17 G4 I Green data
18 G5 I Green data
19 G6 I Green data
20 G7 I Green data (MSB)
