iMX6 Rex Development Baseboard Manual FEDEVEL Academy
www.iMX6Rex.com 2 Document Release: 15-Apr-14
Table of content
Getting started ................................................................................................................................... 3
Connectors ...................................................................................................................................... 10
Jumpers .......................................................................................................................................... 60
LEDs & Buttons ............................................................................................................................... 67
Peripheral selection resistors ........................................................................................................... 79
iMX6 Rex Development Baseboard Manual FEDEVEL Academy
www.iMX6Rex.com 3 Document Release: 15-Apr-14
Getting started
These steps will help you to power up your iMX6 Rex development kit for the very first time.
1. Plug the module into the baseboard
These are the important parts to build the kit:
Notice the position of the thumbs:
iMX6 Rex Development Baseboard Manual FEDEVEL Academy
www.iMX6Rex.com 4 Document Release: 15-Apr-14
2. Add spacers and tight up all the four screws
Notice how the spacer is moved between the module and baseboard:
Plug a screw into the mounting hole and secure it with a nut:
iMX6 Rex Development Baseboard Manual FEDEVEL Academy
www.iMX6Rex.com 5 Document Release: 15-Apr-14
Use a screwdriver to tight it up:
3. Place the heatsink
Remove the red protection foil from the heatsink:
